1.0 OVERVIEW

e Loup Elite Monitor is a full featured display designed to provide accurate population, blockage, bin level, sha RPM and other
readings for gravity drills, air seeders and planters.
information. All aspects and features are detailed but may not be applicable to your system con guration.
THE LOUP ELECTRONICS ELITE MONITOR IS CAPABLE OF MONITORING AND DISPLAYING:
• Ground speed (Implement Mounted Speed Sensor, optional Radar, GPS Speed or Simulated Speed)
• Population in Seeds/Acre (up to 32 sensors can be connected)
• Population readouts for Average Population, Auto Scan, and Section Average are available
• Target Population display along with readout for Percent of Target
• Spacing between seeds or Seeds per Foot (S/FT or IN/S)
• Six sha speed RPM's (Le , Center & Right)
• Seed Flow (up to 192 sensors can be connected)
• Field Area and Total Area
• Rate Calibration
• Six Hoppers (displayed as bargraph display)
• ree Fan Speed Sensors
CUSTOMIZE UP TO 4 TOP DISPLAY WINDOWS WITH THE INFORMATION YOU WANT TO SEE.
SET YOUR
TARGET
POPULATION
LIVE
POPULATION
READOUT
SETUP DRILL
SECTIONS
is manual will familiarize you with operation, calibration and technical
CONFIGURE
UP TO 3
IMPLEMENTS
LOUP ELECTRONICS • 1-877-489-5687 • WWW.LOUPELECTRONICS.COM
ENTER YOUR SELECT YOUR
FARM & FIELD CROP & HYBRID
UP TO 6
BIN LEVEL
SENSORS
AVERAGE FIELD
POPULATION
FIELD & TOTAL
ACRES
3
