Before installation and operation
Please open the package carefully and check for damaged or lost parts.
PARTS INCLUDED:
Collection cup with lid
Diffuser
Air hose
SHARK DC Pump
Recommendations
1.
For best performance, please clean the collection cup frequently. Use a sponge and
warm water to clean it. (DO NOT USE ANY SOAP OR CHEMICALS TO CLEAN THE
COLLECTION CUP).
While we take great care to keep any contaminants away from our products during
2.
assembly, please take a moment to clean with warm water ONLY. Never clean Acrylic
with alcohol-based products. Use caution when handling acrylic scratches easily.
3.
It may require 2 – 4 weeks for the skimmer to reach maximum performance due to
tiny amounts of oil or remnants left from manufacturing. Skimmer performance may
be erratic during this time and be sure to allow ample time for the skimmer to break-in
before making adjustments.
ConeS DCQ Series Protein Skimmer DCQ-2 / DCQ-3
Adjusting valve
Transformer with holder
Pump Controller
Assembling the main unit
1.
Loosen the screws in the bottom of the
skimmer to separate the base and the
skimmer body.
Take the screw under the pump and put the pump on the base then screw back to
2.
combine the pump to the base.
3.
Loosen the center screw on the diffuser to separate the diffuser plate.
4. Loosen the screw beside the cap and put the plate on the pump then screw back.
Make sure to put the plate in the center of the base or the main body cannot be installed.
www.aquamaxxaquariums.com
info@aquamaxxaquariums.com
view from bottom
