- Page 1 Cone-S Q Series In-Sump Protein Skimmer User’s Manual www.aquamaxxaquariums.com info@aquamaxxaquariums.com...
- Page 2 AquaMaxx ConeS Q Series In-Sump Protein Skimmer Footprint 9.5” x 5.9” 6.7” x 9.5” 8.7” x 11.5” 10.7” x 13.4” 16.6” x 13” Height 19.6” 19.3” 19.7” 19.7” 22.9” Motor Shark 1.5 Shark 2.0 Shark 3.0 Shark 6.0 Shark 7.0...
- Page 3 Installation Guide The venturi is press- t into the pump body and can be removed by pulling gently with a twisting motion. Take care when handling so that you do not damage the venturi inlet pipes. Remove the top of the bubble plate assembly by twisting its central thumbscrew in a counter-clockwise motion.
- Page 4 Installation Guide Turn the ve thumbscrews underneath the skimmer base counter-clockwise to detach the skimmer body. With the venturi side facing away from the skimmer’s outlet pipe, position the pump into the base plate notches and secure by twisting the two base plate thumbscrews in a clockwise motion.
- Page 5 Installation Guide Push the press- t venturi into the pump outlet through the opening in the skimmer body. Attach the air silencer to its mount by nger- tightening its central thumbscrew in a clockwise motion. Connect one end of the yellow air line tubing to the bottom pipe on the air silencer.
- Page 6 Installation Guide Connect the silicone drain tube to the outlet pipe on the bottom of the collection cup. If desired, use a zip tie to further secure the drain tube. Ensure the o-ring is securely in place on the skimmer body. Install the collection cup by twisting it clockwise onto the skimmer body.
- Page 7 Operation Guide The pump must be completely submerged underwater when in use. Running the pump dry or in too low of a water level will damage the pump. For proper performance of the quick-precise adjustment valve, the water in your sump must not be any higher than the following levels: Required Water Level 7-8”...
- Page 8 Products requiring warranty service must be returned to AquaMaxx. You are responsible for the cost of shipping a warranty claim to AquaMaxx and any damages that may occur during transit. Once a returned product has been inspected, it will be repaired or exhanged at our discretion and returned to you.
