8 Technical data

Model name ASSKEA proVisio
Flow rate* (measured at 30 l/min ± 2 l/min (high flow)
suction tube nozzle)
Vacuum max. -90 kPa (~ -900 mbar; -675 mmHg)
(high vacuum)
Conversion factor: 1 kPa ~ 7.5 mmHg;
1 kPa ~ 10 mbar
Canister Reusable secretion canister (1 l)
"OneWay" disposable liner (1 l)
Suction tube PVC, inner diameter 6 mm,
(item number: 100713-2) wall thickness 2 mm,
length 150 cm,
vacuum stable up to -0.9 bar
Nominal voltage of the In: AC 100 – 240 V ~ 50-60 Hz / 1.5 A
power supply unit Out: DC 12 V / 5.0 A
Maximum load current 5.0 A
Permissible input voltage 12 V
Power consumption 60 W
at 12 V
Degree of protection Type BF
pursuant to IEC 60601-1
Risk classification IIa
pursuant to 93/42/EEC, IX
Protection class pursuant II
to IEC 60601-1
IP degree of protection IP22
CE marking CE0494
M28 Sound emission
®
Ambient conditions
Battery, rechargeable
Charging time
if battery is empty
Energy of battery pack
Power supply unit
Dimensions of basic
device (H x W x D)
Weight (basic device)
Operating time
Runtime in battery
operation
Expected service life
Item number (REF)
* The information provided may differ depending on the altitude
above sea level, the prevailing air pressure, and the air temperature.
4 Maintenance
Without vacuum: approximately 60 dB(A)
Transport / Storage
Ambient temperature: -25 °C to +70 °C
Relative humidity: up to 90%, non-con-
densing
Air pressure: 700 hPa to 1060 hPa
Operation
Ambient temperature: +5 °C to +40 °C
Relative humidity: 15% to 90%,
non-condensing
Air pressure: 700 hPa to 1060 hPa
at least 10.8 V; lithium ion battery
at least 2 h
<80 Wh
GTM91099-6015-3.0-T2
213 mm x 260 mm x 124 mm
2,8 kg
5 minutes ON; 5 minutes OFF
at least approximately 45 minutes,
depending on the runtime of the motor
5 years
100739 (with reusable secretion canister)
100773 (with disposable secretion
canister system)
