Kramer TP-580RA Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
TP-580RA HDMI Line Receiver
1 Power adapter and cord

Step 2: Get to know your TP-580RA

# Feature
1 PROG Micro USB Port
2 SET UP DIP-switches
3 IN LED
4 OUT LED
5 LINK LED
6 ON LED
7 HDBT IN RJ-45 Connector
8 HDMI OUT Connector
AUDIO
9 S/PDIF RCA Connector
OUT
10 ANALOG 3.5mm Mini Jack
11 IR 3.5mm Mini Jack Connector
12 RS-232 3-pin Terminal Block Connector
13 12V DC Power Connector
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Step 3: Mount TP-580RA

Install TP-580RA using one of the following methods:
•
Attach the rubber feet and place the unit on a flat surface.
•
Fasten a bracket on each side of the unit and attach it to a flat surface
www.kramerav.com/downloads/TP-580RA
(see
•
Mount the unit in a rack using the recommended rack adapter
www.kramerav.com/product/TP-580RA
(see
TP-580RA Quick Start
TP-580RA Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/TP-580RA
upgrades are available.
Function
Connect to a PC to perform firmware upgrades (via K-Upload) and work with the EDID
Designer. K-Upload and EDID Designer can be downloaded from our Web site at:
www.kramerav.com/support.
Used to set the device behavior.
Lights green when an active far-end source HDMI™ input signal is detected via the HDBaseT
link (an HDMI signal is detected from a source device connected to the HDBaseT transmitter
that is connected to this input).
Lights green when a signal is detected on the HDMI output from an active device.
Lights green when a link is established between the TP-580RA and the HDBaseT transmitter.
Lights green when the device receives power.
Connect to the RJ-45 OUT connector on a transmitter (for example, TP-580T).
Connect to an HDMI acceptor.
Connect to a digital stereo audio acceptor.
Connect to an analog unbalanced stereo audio acceptor.
Connect to an external infrared emitter / sensor.
Connect to a controlled device (so that it can be controlled from a remote serial controller);
connect to a laptop to upgrade the firmware or to a control system to serially control the
TP-580RA.
12V DC connector for powering the unit.
).
TP-580RA for the first time.
to download the latest user manual and check if firmware
4 Rubber feet
1 Quick start guide
).
• Ensure that the environment (e.g., maximum ambient temperature &
air flow) is compatible for the device.
• Avoid uneven mechanical loading.
• Appropriate consideration of equipment nameplate ratings should be
used for avoiding overloading of the circuits.
• Reliable earthing of rack-mounted equipment should be maintained.
P/N: 2 9 0 0 - 3 0 0 8 6 3 QS Rev: 4
