Summary of Contents for Prolitec AirQ 880
- Page 1 P ERFEC T LY S C E N TE D E N V IR O NM E N TS AirQ 880 Original Instructions Rev. 2021-04-16...
-
Page 2: Table Of Contents
Appliance Precautions General Care Fragrance Cartridge Precautions FCC Statement – Class B Digital Device Chapter 9: Applications Ambient Scenting Chapter 2: About AirQ 880 Product Marketing Chapter 3: Unpacking Odor Control Chapter 4: MOVING AND STORAGE Aromatherapy and Performance Scenting... -
Page 3: Chapter 1: Important Safety Instructions
If there is any doubt as to whether an outlet box is properly grounded, a qualified electrician should be consulted. • It is recommended that the user remove the appliance from the wall to test and reset the GFCI outlet on a regular basis. AirQ 880 IMPORTANT SAFETY INSTRUCTIONS... -
Page 4: Fragrance Cartridge Precautions
Fragrance Cartridge Precautions • Use only AirQ by Prolitec fragrance cartridges. • Read the Consumer Product Safety Information Sheet and the Material Safety Data Sheet provided with each shipment of Cartridges. Insure that these information sheets are available for review by employees. -
Page 5: Chapter 2: About Airq 880
About AirQ 880 Welcome to a whole new world of air treatment from Prolitec, the technology leader in air care with scent. The AQ880 is the most advanced commercial air-treatment system on the market today. It is the world’s first fully adjustable commercial air-treatment system engineered to serve indoor spaces. - Page 6 This user guide is easy to read. It is also important to read. AQ880 is a high-performance appliance that, installed and used correctly, will meet the most demanding requirements. Table 1. Prolitec AirQ Technology vs. Aerosol Spray Can Technology Parameter...
-
Page 7: Chapter 3: Unpacking
Unpacking Remove the appliance from the container. The following items should be included: 1. AQ880 Appliance 2. Power Supply 3. Key AirQ 880 Unpacking... -
Page 8: Chapter 4: Moving And Storage Instructions
MOVING AND STORAGE INSTRUCTIONS 1. Remove the cartridge. 2. Unplug the appliance. 3. Store at -4°F (-20°C) to 158°F (70°C), 5% to 95% humidity AirQ 880 MOVING AND STORAGE INSTRUCTIONS... -
Page 9: Chapter 5: Installation
The service area range of AQ880 is from 200 to 30,000 cubic (10 to 850 cubic meters). Of course this can vary significantly depending on airflow, number of fresh air changes per hour, temperature, humidity and desired service interval. The AQ880 can be adjusted from 1 to 50 to accommodate these variations. AirQ 880 Installation... -
Page 10: Estimating Cartridge Life
These settings are suggested as a starting point. Start on the lower end of the range and adjust after one hour. Fragrance type, room size, number of fresh air changes per hour, temperature, humidity and user preference will determine the final setting. Best practice is to use AirQ’s ‘S4 Tool’ at AirQ Tools. AirQ 880 Installation... -
Page 11: Appliance Location
AQ880 can use, rather than fight, the natural air currents in a room. 2. Air currents in a room are determined by using a SMOKE TEST KIT available from Prolitec or any source of smoke or vapor, such as a candle or match. -
Page 12: Chapter 6: Scenxus Installation
1. Unpack the appliance as normal, but do not plug it in yet. 2. Remove the extra labels from the Scenxus module. 3. Adhere the remaining ScenXus label inside the appliance door, adjacent to the serial number, and take a photograph. AirQ 880 ScenXus Installation... - Page 13 5. While remaining in the approximate installation location of the appliance, open “settings” on your smart phone and locate “Wi-Fi settings.” 6. Under “Wi-Fi settings,” make sure you see the network that will provide ScenXus internet access. 7. Install the appliance normally, with ScenXus still attached. AirQ 880 ScenXus Installation...
- Page 14 8. Power on the appliance and look for the firmware on the display. 9. The network icon will blink 10. Refresh the list of Wi-Fi networks on the phone until you see a network titled “ScenXus...” AirQ 880 ScenXus Installation...
- Page 15 14. Wait as your smart phone disconnects from ScenXus, ScenXus connects to the router, and the router connects to the internet. When ScenXus is connected to the cloud, you’ll see the message: “connection complete.” 15. The network icon should stop flashing and Wi-Fi signal strength should appear AirQ 880 ScenXus Installation...
-
Page 16: Controlling The Appliance Remotely
Be sure to check your junk and spam folders. 2. On your iPad or Laptop, go to scenxus.com and sign in using your email address and the aforementioned token. 3. Depending on your account, you will see a slightly different version of this homepage. AirQ 880 ScenXus Installation... - Page 17 5. Go to the “Monitor/Control” page and adjust the appliance options and settings as needed. 6. For complex programming, navigate to the SD card programming tool on airqtools.com and download the schedule.txt file to your laptop. 7. Upload the schedule.txt file to the appliance via the “Monitor/Control” page at scenxus.com. AirQ 880 ScenXus Installation...
- Page 18 Internet Explorer relies heavily on cached data, meaning that changes may have been sent to the cloud, but your browser may still show old values. There are settings to prevent this behavior, and other browsers (Chrome, Firefox, Safari, Edge, etc.) do not have this issue. AirQ 880 ScenXus Installation...
-
Page 19: Chapter 7: Operating Instructions
OPERATING INSTRUCTIONS Features and Controls Output Port Lock Air Stem Programming Panel Fragrance Cartridge AirQ 880 OPERATING INSTRUCTIONS... -
Page 20: Setting Up The Cartridge
Place and tighten the plume kit tightly on the cartridge outlet port. If the appliance has been previously programmed, activate preferred setting. If not (see Programming Appliance), press so the backlight turns on, close and lock the door. AirQ 880 OPERATING INSTRUCTIONS... -
Page 21: Programming The Appliance
F”) using • Adjust the status between on (“ ”) and “off” (“ • Press to set the status and the intensity will blink. • Adjust the intensity up or down using AirQ 880 OPERATING INSTRUCTIONS... -
Page 22: Using The Online Usb Programming Tool
Each program set can contain 21 unique programs, which can be turned on or off within the set. • Programs, identified by number 1-21, include a day or days, on/off times, and intensity settings. • The tool will warn the user of overlapping programs. • Programs sets need to be saved. AirQ 880 OPERATING INSTRUCTIONS... - Page 23 2. Insert the USB stick. 3. Press the reset button, and the five buttons will light in sequence from left to right. 4. The buttons will light alternately for about 15 seconds. Do not press any buttons yet. AirQ 880 OPERATING INSTRUCTIONS...
- Page 24 8. Be sure that the power is on and the appliance is in RUN PROGRAM mode prior to closing and locking the door. 9. The new file created on the USB stick will be called “outsche.txt.” Changing it to “schedule.txt” allows the programs to be loaded on another appliance. AirQ 880 OPERATING INSTRUCTIONS...
-
Page 25: Setting Scent Intensity
The Last Step 1. Set the appliance to either 24/7 or RUN PROGRAM. 2. Make sure the power is on. 3. Close and lock the door, storing the key in a known place. AirQ 880 OPERATING INSTRUCTIONS... -
Page 26: Chapter 8: User Maintenance
If no plume, set it back to Run Program and change the cartridge. • • If still no plume, try another cartridge just to make sure. If no plume, replace the appliance. • Wipe the unit clean inside and out. AirQ 880 USER MAINTENANCE... -
Page 27: General Care
When shipping, pack in the original box and place it in an outer cardboard box. • Always keep the plugs in cartridges when not in use. Always remove the cartridge from the appliance before moving it anywhere. Otherwise leakage can occur, destroy the unit and the warranty is voided. AirQ 880 USER MAINTENANCE... -
Page 28: Chapter 9: Applications
There are four basic applications for AQ880: ambient scenting, product marketing, odor control and aromatherapy. These applications are different in terms of their objectives, but they all employ the same combination of Prolitec’s proprietary air-treatment chemistry and AQ880 computer-controlled delivery system. -
Page 29: Product Marketing
AQ880 and Prolitec’s proprietary odor-remediation chemistry are capable of blocking the human ability to detect most malodors and replacing these odors with pleasant scents. Prolitec’s proprietary air-treatment chemistry and the accompanying computer-controlled delivery system are rapidly becoming the standard solution for difficult odor issues in several industry sectors. -
Page 30: Aromatherapy And Performance Scenting
The benefits include reduced errors in routine functions, increased employee sense of well being, higher morale, improved customer service and overall improved productivity. AQ880 and Prolitec aromatherapy chemistry can help make a workspace a more comfortable and appealing place to be. As examples of the positive effect of aromatherapy on the workplace, below are results of several relevant studies: •... -
Page 31: Chapter 10: Frequently Asked Questions
How about safety? Is AQ880 safe to use with children and pets? When used as directed, AQ880 is the safest air freshener available. Of course, it is important to read the Material Safety Data Sheets enclosed with each cartridge, which should be stored in a secure, visible location. AirQ 880 FAQs... - Page 32 How do I clean up a drip? If there is a drip, blot it as quickly as possible and then clean with soap and water. AirQ 880 FAQs...
-
Page 33: Chapter 11: Specifications
85% or less Liquid Capacity 1250 mL cartridges 2500 mL cartridges Service Area Up to 30,000 cu. ft. (850 m3) served Prolitec, Incorporated 1235 W. Canal Street Milwaukee, WI 53223 1-844-247-7599 www.prolitec.com All contents © 2021 Prolitec, Inc. AirQ 880 Specifications...
