Installation & Operation Manual
Zone Valve Control 306V
Introduction
The Zone Valve Control 306V connects up to six thermostats and operates zone valves to provide heating to a zoned
hydronic heating system. The 306V operates a system pump whenever a zone valve opens. Zone 1 can operate either
a zone valve or a circulator to provide heat to an indirect domestic hot water tank with optional priority over zones
2 through 6. The 306V includes optional exercising to prevent circulator seizure when not in use, and optional post
purge operation of the domestic hot water tank to maximize energy savings. The 306V provides a RoomResponse
signal to modulating-condensing boilers to optimize comfort while improving boiler efficiency.
Features
• RoomResponse
signal
TM
• Compatible with all 24 V (ac) thermostats
• Compatible with 2, 3 and 4-wire zone valves
• Unlimited zone expansion
• Zone priority
• Priority override
• Pump exercising
• Post purge
Zone Valve Control 306V
Six Zones with Priority
© 2019 tekmar 306V _ D - 10/19
• LED for each zone, priority, end switch and RoomResponse
• Away signal shared between thermostats
• Four ground screws
• Top, bottom and back conduit knockouts
• Fuses protect transformers and pumps
• Two spare fuses included
• CSA approved
Power
Call
TM
RoomResponse
Zone 1
System
Valve
Priority
Pump
Open
Zone 2
Zone 3
Zone 4
Zone 5
306V _ D
10/19
Zoning
Replaces: 11/16
Zone 6
H3019A
TM
TM
Advertisement
Table of Contents
Related Manuals for Watts tekmar 306V
Summary of Contents for Watts tekmar 306V
- Page 1 • CSA approved • Post purge Power Call RoomResponse Zone 1 Zone 2 Zone 3 Zone 4 Zone 5 Zone 6 System Valve Zone Valve Control 306V Priority Pump Open Six Zones with Priority H3019A © 2019 tekmar 306V _ D - 10/19...
-
Page 2: Table Of Contents
It is your responsibility to ensure that this control is safely installed according to all applicable codes and standards. tekmar is not responsible for damages resulting from improper installation and/or maintenance. This is a safety-alert symbol. The safety alert symbol is shown alone or used with a signal word (DANGER, WARNING, or CAUTION), a pictorial and/or a safety message to identify hazards. When you see this symbol alone or with a signal word on your equipment or in this manual, be alert to the potential for death or serious personal injury. This pictorial alerts you to electricity, electrocution, and shock hazards. This symbol identifies hazards which, if not avoided, could result in death or serious injury. This symbol identifies hazards which, if not avoided, could result in minor or moderate injury. This symbol identifies practices, actions, or failure to act which could result in property damage or damage to the equipment. Read manual and all product labels BEFORE using the equipment. Do not use unless you know the safe and proper operation of this equipment. Keep this manual available for easy access by all users. Replacement manuals are available at tekmarControls.com • It is the installer’s responsibility to ensure that this control is safely installed according to all applicable codes and standards. • Improper installation and operation of this control could result in damage to the equipment and possibly even personal injury or death. • This control is not intended for use as a primary limit control. Other controls that are intended and certified as safety limits must be placed into the control circuit. The control includes fuses and transformer that are serviceable. Do not attempt to service any other parts on the control. Attempting to service the control voids the warranty. • Strip all wiring to a length of 3/8 in. or 10 mm for all terminals. • A circuit breaker or power disconnect that provides power to the control should be located nearby and clearly labeled. • Refer to the current and voltage ratings at the back of this manual before connecting devices to this control. © 2019 tekmar 306V _ D - 10/19 2 of 12... -
Page 3: Installation
• 1 Installation and Operation Manual 306V_D • 2 Spare fuses (located in cover) Location • Keep the control dry. Avoid potential leakage onto the control. • Maintain relative humidity less than 90% in a non-condensing environment. • Avoid exposure to extreme temperatures beyond 32-122°F (0-50°C). • Install away from equipment, appliances, or other sources of electrical interference. • Install to allow easy access for wiring, viewing, and adjusting the display screen. • Install approximately 5 feet (1.5 m) off the finished floor. • Locate the control near pumps and/or zone valves if possible. • Provide a solid backing which the enclosure can be mounted to. Example: plywood or wall studs. • Use the conduit knockouts provided on the upper, lower, and back of the enclosure for wiring. Installing the Enclosure To prevent the risk of personal injury and/or death, make sure power is not applied to the control until it is fully installed and ready for final testing. All work must be done with power to the circuit being worked on turned off. Please be aware local codes may require this control to be installed or connected by an electrician. © 2019 tekmar 306V _ D - 10/19 3 of 12... -
Page 4: Application 306V-1
120 VAC SYSTEM PRIORITY POWER PUMP PUMP 1 ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 MOTOR MOTOR MOTOR MOTOR MOTOR MOTOR SWITCH SWITCH SWITCH SWITCH SWITCH SWITCH © 2019 tekmar 306V _ D - 10/19 4 of 12... -
Page 5: Application 306V-2
ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 MOTOR MOTOR MOTOR MOTOR MOTOR MOTOR SWITCH SWITCH SWITCH SWITCH SWITCH SWITCH 1 2 3 1 2 3 End switch jumper required for Zone 1 when using a pump and Zone Valve End © 2019 tekmar 306V _ D - 10/19 Switch DIP = On 5 of 12... -
Page 6: Application 306V-3
SWITCH SWITCH SWITCH SWITCH SWITCH SWITCH SWITCH DIP Switches - Master DIP Switches - Member Master Mod Boiler = depends on boiler Member Mod Boiler = depends on boiler T-stat 1 Priority = On System Pump During Priority = Off T-stat 1 Priority = Off System Pump During Priority = Off Exercising = On System Pump With Member Calls = On Exercising = On System Pump With Member Calls = Off Post Purge = On Zone Valve End Switches = On Post Purge = On Zone Valve End Switches = On © 2019 tekmar 306V _ D - 10/19 6 of 12... -
Page 7: User Interface
4-wire zone valves. • The boiler end switch XX only closes when the DIP switch Off: System pump and boiler turn on immediately when a is set to Master and does not close when set to Member. thermostat calls for heat. Select this option when using 2-wire T-Stat 1 Priority DIP Switch zone valves. When T-Stat 1 is calling for heat by closing the R and W terminals: Fuses • 115 V (ac) is applied to the Priority Pump 1. • All fuses are T5A 250V slow blow. • Zone 1 indicator LED is turned on. • Fuse 1 and 2 correspond to the 24 V (ac) transformer power • Priority indicator LED is turned on. supply. If a fuse is blown, first check that the thermostat wiring • Zones 2 to 6 zone valves and LEDs are turned off. is not shorted. Then replace the fuse. • Expansion Member controls shut off their zones. © 2019 tekmar 306V _ D - 10/19 7 of 12... -
Page 8: Technical Data
Lochinvar FTXL ® NTI Trinity Fire Tube and LX Not required 4-20 mA Peerless PureFire PFA-1 Adapter 0-10 V Raypak Xfyre, Xtherm, MVB, XPakFT Not required 0-10 V Not required 0-10 V 100% Riverside HeatStation OpenTherm Viessmann 100-W, WB1B 0-10 V 100% Module Viessmann 200-W, B2HB and 300 CU3A Not required 0-10 V Not required 0-10 V 100% Weil-McLain Evergreen ® * Requires changes to boiler's settings © 2019 tekmar 306V _ D - 10/19 8 of 12... - Page 9 – – – 1 2 9 10 5 6 11 12 Burnham Laars 306V 306V Alpine Mascot LX • Change Parameter 9 Remote 4-20 mA to Setpoint Source. • Change Installer Parameter 25 "0-10V to Power" to Disabled. • Change "Energy Management" setting "Central Heat • Change Installer Parameter 26 "0-10V to outlet setpoint" to Modulation Source" to 4-20 mA. Disabled. • Change "Energy Management" setting "Central Heat 4-20 mA Setup, 4 mA Water Temperature" to 80°F (26.5°C). © 2019 tekmar 306V _ D - 10/19 9 of 12...
- Page 10 306V Riverside HeatStation • Set boiler PIM DIP switch 2 to Off. • Set boiler PIM DIP switch 5 to On. • Set boiler PIM DIP switch 6 to Off. – • Set APP parameter to EMS – 3 5 11 12 • Set SIGNAL parameter to 0-10Vdc • Set SETP LO to 70°F 306V NTI Trinity LX • Set SETP HI to 180°F • Enter boiler password. • Set Parameter "Setpoint source" to 4-20mA © 2019 tekmar 306V _ D - 10/19 10 of 12...
- Page 11 WB1B ------ -------- – – Viessmann 306V OpenTherm Module • Install the OpenTherm Module as per the boiler manufac- turer's instructions. Viessmann Vitodens 200-W, B2HP and Vitocrossal 300 CU3A ---- ---------- ----------- -- – – Viessmann 306V Extension Module EA1 Plug 0-10V © 2019 tekmar 306V _ D - 10/19 11 of 12...
-
Page 12: Limited Warranty And Product Return Procedure
California to cause cancer and birth defects or other reproductive harm. Purchaser’s sole responsibility and obligation. Purchaser shall indemnify and hold For more information: Watts.com/prop65 All specifications are subject to change without notice Tel: (250) 545-7749 • Fax: (250) 984-0815 tekmarControls.com...
