- Page 1 78-2055-250 9/16 Lionel Lionel Command Control Command Control Trackside Crane Trackside Crane Owner’s Manual Owner’s Manual Featuring...
- Page 2 3-pin cable that connects directly to a Plug-Expand-Play Lock-on track section. There are separate-sale cables that allow you to expand your system to meet your needs. The following Lionel marks are used throughout this Owner’s Manual and are protected under law. All rights reserved. ®...
-
Page 3: Table Of Contents
Operating the Trackside Crane CAB-2 Remote Controller commands CAB-1 and CAB-1L Remote Controller commands Assigning a new ID# to your Trackside Crane Maintenance and Service Storing the Trackside Crane Restringing the Trackside Crane 14-15 Servicing the LEDs Lionel Limited Warranty Policy & Service... -
Page 4: Trackside Crane Basics
Trackside Crane basics Preparing the Trackside Crane for operation o prepare the Trackside Crane for operation, press the small gear back into position, gently swivel the cab until the teeth align. Slide the lever back towards the gears to lock the gears in position. -
Page 5: Wiring Your Trackside Crane For Plug-Expand-Play
Trackside Crane basics Wiring your Trackside Crane for Plug-Expand-Play our Trackside Crane connects to either a Plug-Expand-Play lock-on (6-81313) or a Plug-Expand-Play power block lock-on (6-81314) with the 3-pin male connector that is attached to its base. Simply plug this connector into the lock-on and apply track power. To turn the accessory OFF, unplug the 3-pin connector from the lock-on or turn off the track power. -
Page 6: Connecting Your Accessory To Fastrack
Trackside Crane basics Connecting your accessory to FasTrack ou also are able to connect your crane to FasTrack using an 8" 3-pin female pigtail (available separately, 6-82038). Plug in the 3-pin male connector from the accessory into the 3-pin female pigtail. Then attach the red wire to the inside rail and the black wire to the outside rail. -
Page 7: Connecting Your Accessory To Tubular Track
Trackside Crane basics Connecting your accessory to tubular track ou can also connect the crane to tubular track using an 8" 3-pin female pigtail (available separately, 6-82038). Plug in the 3-pin male connector of the accessory into the 3-pin female pigtail. Then attach the red wire to the inside rail position of the universal lock-on (6-24213) and the black wire to the outside rail position. -
Page 8: Connecting Your Accessory To A Transformer
Trackside Crane basics Connecting your accessory to a transformer o power your crane using a CW-80 Transformer (6-14198)or any other power supply, you will need an 8" 3-pin female pigtail (available separately, 6-82038) to connect to the transformer terminals. Make sure that all connections are secure. Loose connections can produce extremely high temperatures. -
Page 9: Capabilities Of The Trackside Crane
Trackside Crane basics Capabilities of the Trackside Crane our Trackside Crane was designed to hoist objects from a stationary position. When the boom is raised to its highest point, the main hook is capable of hoisting about 19 oz (1-1/5 lb) and the auxiliary hook is capable of hoisting about 14 oz (7/8 lb). -
Page 10: Cab-2 Remote Controller Commands
Operating the Trackside Crane The LEGACY CAB-2 Remote Controller se your CAB-2 Remote Controller to operate your Trackside Crane. Raises and Lowers the Raises and Lowers the Boom. main hook on the Crane. Use the Boost/Brake button Use the Boost/Brake to move the boom up and button to move the hook down. -
Page 11: Cab-1 And Cab-1L Remote Controller Commands
Operating the Trackside Crane CAB-1 & CAB-1L Remote Controller commands se your CAB-1 Remote Controller to operate the Trackside Crane. Lowers the Boom. Raises the Boom. Rotates the crane cab. You can operate the hooks or the Note boom while the cab is rotating. Lowers the main hook on the crane. -
Page 12: Assigning A New Id To Your Trackside Crane
Operating the Trackside Crane Assigning a new ID to your Trackside Crane s your fleet of LEGACY or TMCC equipped locomotives and equipment grows, you will want to assign each unit a unique ID#. Use your CAB-1, CAB-1L, or CAB-2 Remote Controller. 1. -
Page 13: Maintenance And Service
Maintenance and Service Storing the Trackside Crane hen you are ready to store your Trackside Crane, be sure to use rubber bands to keep tension on the hook lines. Use your remote to position the boom to fit in the foam cavity. As illustrated in Figure 7, open the front right-hand cab door and slide the lever towards the boom to disengage the cab rotation gears. -
Page 14: Restringing The Trackside Crane
Be sure to position the strings as discussed in this section to prevent the strings from breaking. Note If a string breaks, do not attempt to knot the string. See your authorized Lionel Service Center or Lionel Service for a non-warranty repair. Auxiliary hook The auxiliary hook is operated using a single string, which is approximately 48 inches long. -
Page 15: Servicing The Leds
Figure 9. Routing the boom string Replacing the lamps our Trackside Crane is illuminated by several LEDs. The LEDs are expected to last for the life of this product and are not user serviceable. Contact Lionel Service if your LEDs need replacing. -
Page 16: Lionel Limited Warranty Policy & Service
Lionel LLC or any Lionel Authorized Service Station MUST be accompanied by the original receipt for purchase (or copy) from an Authorized Lionel Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
