- Page 1 VENTILATOR USER GUIDE MODEL 724BCB...
-
Page 3: Table Of Contents
BRAKE COOLING FAN USER GUIDE This manual covers the description, cautions, operation, and maintenance of the Super Vac 724BCB. Please take the time to read this manual before operating the fan. Save this guide for future reference. CONTENTS 1. BREAKAGE OR DAMAGE DURING SHIPMENT .................................. -
Page 4: Breakage Or Damage During Shipment
These damaged goods, of course, will belong to them, and they will inform you what to do with them. If you dispose of these damaged goods, your claim may not be paid. 724BCB User Guide Revised 1-2018... -
Page 5: General Description And Specifications
BRAKE COOLING FAN 2. General Description and Specifications Super Vac ventilators are specifically designed to provide a convenient and portable source of air. Model Voltage Motor HxWxD Weight 24 V DC, 108 lb 724BCB 2500 Totally Enclosed Air Over ( TEAO) 35”... -
Page 6: Before Operating Ventilator
Place ventilator in desired location before connecting battery pack. Use caution not to direct toxic fumes into confined spaces with the ventilator. Please refer to the Super Vac Training Manual for Smoke Ventilation for comprehensive instruction on effective ventilation practices. -
Page 7: Charging The Battery Pack
Intake and exhaust guards are not interchangeable. When replacing guards after cleaning, position them with the rings to the outside with the row of spot welds holding the rings on the bottom. 724BCB User Guide Revised 1-2018... -
Page 8: Warranty
4. Any service other than our Authorized Service voids this warranty. 5. This warranty is in lieu of and is intended to exclude all other warranties, express or implied, oral or written, including any warranties of MERCHANTABILITY or FITNESS for a particular purpose. 724BCB User Guide Revised 1-2018... -
Page 9: Contact Information
BRAKE COOLING FAN 9. Contact Information For parts or service information, contact: Super Vacuum Manufacturing Company, Inc. 3842 Redman Dr. Fort Collins, CO 80524 Phone: 800-525-5224 970-297-7100 Fax: 970-297-7099 Email : info@supervac.com Internet: www.supervac.com 724BCB User Guide Revised 1-2018... -
Page 10: Parts List
PART NUMBER DESCRIPTION 018-15049 FRAME, 724BCB 018-15050 LIFT MECHANISM 008-13373 WHEEL PNEUMATIC DW414 3" HUB CENTER 021-14922 MOTOR FOR 724BCB 1HP TEFC BI-DIR 019-10461 724 HANDLE PAINTED INTAKE PLENUM 003-14150 BLADE, INLET CONE, PB831 #C-TO-ICP280 012-14143 GUARD, 724BCB FRONT-PAINTED 003-14149... -
Page 11: Exploded View
BRAKE COOLING FAN 11. Exploded View 724BCB User Guide Revised 1-2018... -
Page 12: Lift Assembly
GAS SPRING GAS SPRING MOUNT MOUNT, GAS SPRING 008-10211 CAP,FAN,HANDLE,718 034-11057 NUT,NYLOCK, 5/16-18 UNC,SS STD HARDWARE LW39 WASHER,LOCK,SPRING,REGULAR, 5/16", SS STD HARDWARE-HHCS-235 SCREW,HH,5/16-24x1-1/2,SS STD HARDWARE W24 WASHER,FLAT,USS, 5/16", SS STD HARDWARE-HHCS-35 SCREW,HH,5/16-18x1-1/2,SS AS568A-015 ORING,ID 0.551,SIZE 0.551,AS568A-015 724BCB User Guide Revised 1-2018...
