Side View Frequency

(Side Imaging® and Down Imaging™ Views only
[898c SI, 998c SI]
Settings: 800 kHz or 455 kHz; Default = 455 kHz
Side View Frequency allows you to select which frequency to apply to the
Side Imaging® beams (800 kHz or 455 kHz).

Surface Clutter

Settings: Low = 1 to High = 10; Default = 5
Surface Clutter adjusts the filter that removes surface clutter noise caused
by algae and aeration. The lower the setting, the less surface clutter will be
displayed.
Surface Clutter
SwitchFire™ controls how the sonar returns are displayed in the Sonar
Views.
Choose Max Mode to see only raw sonar returns on the display. When Max
Mode is selected, you will see the maximum sonar information available
within the transducer beam, so more fish arches and better jig tracking are
shown.
Choose Clear Mode to see less clutter and more fish size accuracy on the
display. When Clear Mode is selected, the clutter is filtered, and sonar
returns are interpreted to provide more details about the objects within the
transducer beam, regardless of their location. In other words, a large arch on
the display means a large fish has been detected.
109

SwitchFire™

Settings: Clear Mode, Max Mode; Default = Clear
Mode
Sonar Menu Tab
