UM10574
PCA9685 demonstration board OM13332
Rev. 1 — 1 April 2014
Document information
Info
Content
Keywords
Fm+ I2C-bus, PCA9685, RGB and White LEDs, 16 channel x 12-bit PWMs
Abstract
The OM13332 is an add-on to 9-pin connector of the NXP I2C demo board 2005-1
or Fm+ I2C Bus development board. This daughter board makes it easy to test
and design with the PCA9685, the LED output driver is programmed to be either
open-drain with a 25 mA current sink capability at 5 V or totem pole with a 25 mA
sink. The PCA9685 operates with a supply voltage range of 2.3 V to 5.5 V and the
inputs and outputs are 5.5 V tolerant. This demo board, along with the
Win-I2CUSB Lite GUI (PC based), provides an easy to use evaluation platform.
User manual
