FIC VC19 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DOC No.: M02205
Rev.
: A0
Date
: 5, 2002
Part No. : 25-11647-00

Advertisement

Table of Contents
loading

Related Manuals for FIC VC19

Summary of Contents for FIC VC19

  • Page 1 DOC No.: M02205 Rev. : A0 Date : 5, 2002 Part No. : 25-11647-00...

  • Page 2: Handling Precautions

    Notice Handling Precautions Warning: 1. Static electricity may cause damage to the integrated circuits on the motherboard. Before handling any motherboard outside of its protective packaging, ensure that there is no static electric charge in your body. 2. There is a danger of explosion if the battery is incorrectly replaced.
  • Page 3 Table of Contents Table of Contents Quick Reference (German) Quick Reference (French) Quick Reference (Spanish) Quick Reference (Japanese) Quick Reference (Chinese) Quick Reference (Simplified Chinese) |||||||||||||SC-1 Chapter 1 Overview Chapter 2 Installation Procedures...
  • Page 4 VC19 Mainboard Manual Chapter 3 BIOS Setup...
  • Page 5 Chapter 1 Overview Overview 1 - 1...

  • Page 6: Package Checklist

    VC19 Mainboard Manual Package Checklist The mainboard This user manual One FDD cable |Software CD One ATA/100 cable NOTE: CD Pro that contains patch files, onboard video/audio chip drivers, related online help and other useful information can be found in your mainboard package.
  • Page 7 Overview The VC19 Mainboard 1 - 3...

  • Page 8: Main Features

    VC19 Mainboard Manual Main Features 1 - 4...
  • Page 9 Overview 1 - 5...

  • Page 10: Fic Unique Innovation For Users (Novus)

    VC19 Mainboard Manual FIC Unique Innovation for Users (NOVUS) - Enhanced Mainboard Features and System Support NOTE: 1. LogoGenie supports Award BIOS only. 2. If you create a Logo file (.bmp) by LogoGenie, the file size must ||||be 640 x 464 x 256 colors.

  • Page 11: Installation Procedures

    Installation Procedures Chapter 2 Installation Procedures WARNING: Excessive torque may damage the mainboard. When using an electric screwdriver on the mainboard, make sure that the torque is set to the allowable range of 5.0 ~ 8.0kg/cm. Mainboard components contain very delicate Integrated Circuit (IC) chips.
  • Page 12 VC19 Mainboard Manual Quick Reference (from Page 2-2 to 2-4) Mainboard Layout 2 - 2...
  • Page 13 Installation Procedures Clear CMOS, Clear Password, FSB Speed Select Front Panel Block Cable Connection 2 - 3...

  • Page 14: Set System Jumpers

    VC19 Mainboard Manual CPU Fan Installation 1). Set System Jumpers NOTE: Users are not encouraged to change the jumper/switch set- tings not listed in this manual. Changing the settings improperly may adversely affect system performance. 2 - 4...
  • Page 15 Installation Procedures 2 - 5...

  • Page 16: Install Memory Modules

    VC19 Mainboard Manual 2). Install Memory Modules NOTE: Usually, the DIMM3 socket is reserved. It will be used only when users install two single-bank DIMM modules on DIMM2 and DIMM3 respectively. In other words, only two types of DIMM installation are allowed: (1).

  • Page 17: Install The Cpu

    Installation Procedures 3). Install the CPU NOTE: Users The CPU installing procedures should be: 1. Insert the CPU (with its fansink and retention module) on the socket. 2. Connect the 20-pin plug of the power supply 3. Connect the 4-pin plug of the power supply. To remove the processor, please do it in reverse order.

  • Page 18: Install Expansion Cards

    VC19 Mainboard Manual 4). Install Expansion Cards CAUTION: Make sure to unplug the power supply when adding or removing expansion cards or other system components. Failure to do so may cause severe damage to both the mainboard and ex- pansion cards.

  • Page 19: Connect Devices

    Installation Procedures 5). Connect Devices 2 - 9...
  • Page 20 VC19 Mainboard Manual 2 - 10...
  • Page 21 Installation Procedures 2 - 11...
  • Page 22 VC19 Mainboard Manual 2 - 12...
  • Page 23 Installation Procedures NOTE: When a dual power LED is used, Pin 2 is for green one and Pin 4 is for yellow one. If single power LED installed, Pin 2 is for positive and Pin 4 is for negative. 2 - 13...
  • Page 24 VC19 Mainboard Manual 2 - 14...
  • Page 25 Installation Procedures NOTE: If your VC19 board has LAN on it. The onboard LAN function is not allowed to be disabled. 2 - 15...
  • Page 26 VC19 Mainboard Manual NOTE: If you do not use F_AUDIO, please keep the pinpair 5-6, 9-10 short as default; also, when the front headphone is plugged in, the rear audio output will be disabled. NOTE: If your mainboard has 5.1-channel audio option, the LINE_IN, LINE_OUT, MICROPHONE jacks can be the 5.1-channel audio out-...
  • Page 27 Installation Procedures 2 - 17...
  • Page 28 VC19 Mainboard Manual 2 - 18...

  • Page 29: Cmos Setup Utility

    BIOS Setup Chapter 3 BIOS Setup CMOS Setup Utility 3 - 1...
  • Page 30 VC19 Mainboard Manual Standard CMOS Setup Date Time 3 - 2...
  • Page 31 BIOS Setup Hard Disks Hard Disk Configurations Drive A / Drive B Floppy 3 Mode Support Video Halt On 3 - 3...

  • Page 32: Advanced Bios Features

    VC19 Mainboard Manual Advanced BIOS Features Virus Warning CPU L1 & L2 Cache Quick Power On Self Test Hard Disk Boot Priority First/Second/Third Boot Device 3 - 4...
  • Page 33 BIOS Setup Boot Other Device Swap Floppy Drive Boot Up Floppy Seek Boot Up Numlock Status Gate A20 Option Typematic Rate Setting Typematic Rate (Chars/Sec) Typematic Delay (Msec) 3 - 5...
  • Page 34 VC19 Mainboard Manual Security Option APIC Mode MPS Version Control For OS OS Select For DRAM > 64MB HDD S.M.A.R.T. Capability Report No FDD For WIN 95 BIOS Guardian NOTE: Please disable this BIOS feature before you start to reflash BIOS.
  • Page 35 BIOS Setup BIOS Guardian and Reflash BIOS Full Screen LOGO Show 3 - 7...

  • Page 36: Advanced Chipset Features

    VC19 Mainboard Manual Advanced Chipset Features DRAM Timing Selectable CAS Latency Time Active to Precharge Delay DRAM RAS# to CAS# Delay DRAM RAS# Precharge 3 - 8...
  • Page 37 BIOS Setup Memory Frequency For Dram Read Thermal Mgmt System BIOS Cacheable Video BIOS Cacheable Memory Hole At 15M-16M Delayed Transaction Delay Prior to Thermal 3 - 9...

  • Page 38: Integrated Peripherals

    VC19 Mainboard Manual AGP Graphics Aperature Size (MB) Integrated Peripherals On-Chip Primary PCI IDE IDE Primary Master PIO IDE Primary Slave 3 - 10...
  • Page 39 BIOS Setup IDE Primary Master UDMA IDE Primary Slave UDMA On-Chip Secondary PCI IDE IDE Secondary Master PIO IDE Secondary Slave PIO IDE Secondary Master UDMA IDE Secondary Slave UDMA USB Controller 3 - 11...
  • Page 40 VC19 Mainboard Manual USB Keyboard Support AC97 Audio Init Display First Onboard Sound ChipOnboard Onboard Raid Chip IDE HDD Block Mode POWER ON Function KB Power ON Password 3 - 12...
  • Page 41 BIOS Setup Hot Key power ON Onboard FDC Controller Onboard Serial Port 1/2 UART Mode Select RxD , TxD Active IR Transmission Delay UR2 Duplex Mode Use IR Pins 3 - 13...
  • Page 42 VC19 Mainboard Manual Onboard Parallel Port Parallel Port Mode EPP Mode Select ECP Mode Use DMA PWRON After PWR-Fail Game Port Address 3 - 14...

  • Page 43: Power Management Setup

    BIOS Setup Power Management Setup ACPI Function ACPI Suspend Type Run VGABIOS if S3 Resume Power Management 3 - 15...
  • Page 44 VC19 Mainboard Manual Video Off Method Video Off In Suspend Suspend Type MODEM Use IRQ Suspend Mode HDD Power Down Soft-Off by PWR-BTTN 3 - 16...
  • Page 45 BIOS Setup CPU THRM-Throttling Wake-Up by PCI card Power On by Ring Wake Up On LAN USB KB Wake-Up From S3 Resume by Alarm Date (of Month) Alarm Time (hh:mm:ss) Alarm 3 - 17...
  • Page 46 VC19 Mainboard Manual Primary IDE 0 Primary IDE 1 Secondary IDE 0 Secondary IDE 1 FDD, COM, LPT Port PCI PIRQ[A-D]# 3 - 18...

  • Page 47: Pnp/Pci Configurations

    BIOS Setup PnP/PCI Configurations Reset Configuration Data Resources Controlled By PCI/VGA Palette Snoop INT Pin 1/2/3/4/5/6/7/8 Assignment 3 - 19...

  • Page 48: Pc Health Status

    VC19 Mainboard Manual PC Health Status CPU Warning Temperature Current System Temp. / Current CPU Temperature / Current CPU Fan Speed / Current SYS FAN Speed / CPU Vcore / +1.5V / 3.3V / +5V / +12V / -12V / -5V / VBAT(V) / 5VSB(V)

  • Page 49: Frequency/Voltage Control

    BIOS Setup Frequency/Voltage Control CPU Clock Ratio Auto Detect PCI Clk Spread Spectrum CPU Host/3V66/PCI Clock 3 - 21...
  • Page 50 VC19 Mainboard Manual Load Fail-Safe Defaults Load Optimized Defaults Supervisor/User Password Save and Exit Setup Exit without Saving 3 - 22...
