Summary of Contents for CommScope SYSTIMAX AirSPEED AP541

  • Page 2: Table Of Contents

    Getting Started ..........16 SYSTIMAX AirSPEED AP541 Hardware Description ......16 Dual Band Signal Enhancing Antenna Description .
  • Page 3   Contents SYSTIMAX AirSPEED AP541 User Guide User Guide Viewing Status Information ........29 Logging into the HTTP Interface .
  • Page 4   Contents SYSTIMAX AirSPEED AP541 User Guide User Guide Uploading Externally Generated Host Keys ........57 Serial Configuration Settings .
  • Page 5   Contents SYSTIMAX AirSPEED AP541 User Guide User Guide Adding or Modifying a RADIUS Server Profile ........83 MAC Access Control Via RADIUS Authentication .
  • Page 6   Contents SYSTIMAX AirSPEED AP541 User Guide User Guide Enabling and Viewing Station Statistics ......... .115 Refreshing Station Statistics .
  • Page 7   Contents SYSTIMAX AirSPEED AP541 User Guide User Guide VLAN Workgroups ............132 Power over Ethernet (PoE) .
  • Page 8   Contents SYSTIMAX AirSPEED AP541 User Guide User Guide Configuring Objects that Require Reboot ........148 “set”...
  • Page 9   Contents SYSTIMAX AirSPEED AP541 User Guide User Guide DHCP Server Parameters ..........167 DHCP Relay Group .
  • Page 10   Contents SYSTIMAX AirSPEED AP541 User Guide Command Syntax and Examples of Configuring Security Profiles: ....187 Other Parameters ............189 IAPP Parameters .
  • Page 11   Contents SYSTIMAX AirSPEED AP541 User Guide 802.11a ............. . 201 802.11g .

  • Page 12: Introduction

      SYSTIMAX AirSPEED AP541 User Guide AP 4000 User Guide Introduction • Document Conventions • Introduction to Wireless Networking • IEEE 802.11 Specifications • Management and Monitoring Capabilities Document Conventions • The term, AP, refers to an Access Point. •...

  • Page 13: Guidelines For Roaming

      Introduction SYSTIMAX AirSPEED AP541 User Guide User Guide A wireless network provides: • Seamless client roaming (not available with 802.1x security) • Easy installation and operation • Over-the-air encryption of data • High speed network links Guidelines for Roaming •...

  • Page 14: Ieee 802.11 Specifications

      Introduction SYSTIMAX AirSPEED AP541 User Guide User Guide IEEE 802.11 Specifications In 1997, the Institute of Electrical and Electronics Engineers (IEEE) adopted the 802.11 standard for wireless devices operating in the 2.4 GHz frequency band. This standard includes provisions for three radio technologies: direct sequence spread spectrum, frequency hopping spread spectrum, and infrared.

  • Page 15: Snmp Management

      Introduction SYSTIMAX AirSPEED AP541 User Guide User Guide SNMP Management In addition to the HTTP and the CLI interfaces, you can also manage and configure an AP using the Simple Network Management Protocol (SNMP). Note that this requires an SNMP manager program, like HP Openview or Castlerock’s SNMPc.

  • Page 16: Getting Started

    Additional Hardware Features SYSTIMAX AirSPEED AP541 Hardware Description The SYSTIMAX AirSPEED AP541 is a tri-mode AP that can support 802.11b, 802.11g, and 802.11a clients. The AirSPEED AP541 contains a single embedded 802.11a/b/g radio. The unit is software programmable to operate in one of four modes: 802.11b mode, 802.11g mode, 802.11b/g mode, or 802.11a mode.

  • Page 17: Dual Band Signal Enhancing Antenna Description

      Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide Dual Band Signal Enhancing Antenna Description The AirSPEED AP541 can use internal or external antennas. The AirSPEED AP541 has two diversity antennas embedded for the radio. The internal antennas are arranged to provide both spatial and polarization diversity. The AirSPEED AP541 also has two external antenna connectors for use with the Dual Band Signal Enhancing Antenna (SEA).

  • Page 18: Product Package

      Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide Product Package • AirSPEED AP541 unit (with integrated 802.11a/b/g radio, and Power over Ethernet) • Power adapter • One ceiling or wall mounting plate. • One installation CD-ROM that contains the following: –...

  • Page 19: Initialization

      Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide Initialization SYSTIMAX provides two tools to simplify the initialization and configuration of an AP: • ScanTool • Setup Wizard ScanTool is included on the Installation CD; the Setup Wizard launches automatically the first time you access the HTTP interface.
  • Page 20   Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide NOTE If your computer has more than one network adapter installed, you will be prompted to select the adapter that you want ScanTool to use before the Scan List appears. If prompted, select an adapter and click OK. You can change your adapter setting at any time by clicking the Select Adapter button on the Scan List screen.

  • Page 21: Setup Wizard

      Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide Figure 2-3 Scan Tool Change Screen Set IP Address Type to Static. Enter a static IP Address for the AP in the field provided. You must assign the unit a unique address that is valid on your IP subnet.
  • Page 22   Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide Figure 2-4 Enter Network Password Figure 2-5 Setup Wizard 5. Click Setup Wizard to begin. If you want to configure the AP without using the Setup Wizard, click Exit and see Performing Advanced Configuration.
  • Page 23   Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide 8. Assign the AP new passwords to prevent unauthorized access and click Save & Next. Each management interface has its own password: — SNMP Read Password — SNMP Read-Write Password —...

  • Page 24: Download The Latest Software

      Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide — Multicast Rate: Sets the rate at which Multicast messages are sent. The table below displays the possible Multicast Rates. See Multicast Rate for more information. Multicast Rate 1 and 2 Mbits/s 1, 2, and 5.5 Mbits/s 1, 2, 5.5 and 11 Mbits/s 1, 2, 5.5 and 11 Mbits/s...

  • Page 25: Download Updates From Your Tftp Server Using The Cli Interface

      Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide 7. Select Download & Reboot from the File Operation drop-down menu. 8. Click OK. 9. The Access Point will reboot automatically when the download is complete. Download Updates from your TFTP Server using the CLI Interface 1.

  • Page 26: Power Over Ethernet (Poe)

      Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide Power over Ethernet (PoE) The AirSPEED AP541 is equipped with an 802.3af-compliant Power over Ethernet (PoE) module. Power over Ethernet delivers both data and power to the Access Point over a single Ethernet cable. SYSTIMAX recommends using a midspan Power over Ethernet device to power the AP as an alternative to the power adaptor.
  • Page 27   Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide The LED indicators exhibit the following behavior: Indication Power Wireless Interface A Ethernet (802.11a/b/g radio) Solid Green AP image running. Wireless interface A has The Ethernet interface is traffic. connected at 100 Mbps with no traffic Blinking...
  • Page 28   Getting Started SYSTIMAX AirSPEED AP541 User Guide User Guide Related Topics The Setup Wizard helps you configure the basic AP settings required to get the unit up and running. The AP supports many other configuration and management options. The remainder of this user guide describes these options in detail. –...

  • Page 29: Viewing Status Information

      SYSTIMAX AirSPEED AP541 User Guide User Guide Viewing Status Information • Logging into the HTTP Interface • System Status Logging into the HTTP Interface Once the AP has a valid IP Address and an Ethernet connection, you may use your web browser to monitor the system status.

  • Page 30: System Status

      Status Information SYSTIMAX AirSPEED AP541 User Guide User Guide System Status System Status is the first screen to appear each time you connect to the HTTP interface. You can also return to this screen by clicking the Status button. Figure 3-2 System Status Screen Each section of the System Status screen provides the following information:...

  • Page 31: Performing Advanced Configuration

      SYSTIMAX AirSPEED AP541 User Guide User Guide Performing Advanced Configuration • Configuring the AP Using the HTTP/HTTPS Interface • System Tab: Configure specific system information such as system name and contact information. • Network Tab: Configure IP settings, DNS client, DHCP server, DHCP Relay Agent, DHCP Relay Servers, and Link Integrity.
  • Page 32   Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Figure 4-1 Enter Network Password Screen 5. Click the Configure button located on the left-hand side of the screen. Figure 4-2 Configure Main Screen 6. Click the tab that corresponds to the parameter you want to configure. For example, click Network to configure the Access Point’s TCP/IP settings.

  • Page 33: System Tab

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide System Tab You can configure and view the following parameters within the System Configuration screen: • Name: The name assigned to the AP. Refer to the Dynamic DNS Support Access Point System Naming Convention sections for rules on naming the AP.

  • Page 34: Access Point System Naming Convention

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Access Point System Naming Convention The Access Point's system name is used as its host name. In order to prevent Access Points with default configurations from registering similar host names in DNS, the default system name of the Access Point is uniquely generated.

  • Page 35: Network Tab

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Network Tab The Network category contains four sub-categories. – IP Configuration Sub-tab – DHCP Server Sub-tab – DHCP Relay Agent Sub-tab – Link Integrity Sub-tab IP Configuration Sub-tab This tab is used to configure the internet (TCP/IP) settings for the Access Point. These settings can be either entered manually (static IP address, subnet mask, and gateway IP address) or obtained automatically (dynamic).The DNS Client functionality can also be configured, so that host names used for configuring the Access Point can be resolved to their IP addresses.
  • Page 36   Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide You can configure and view the following parameters within the IP Configuration sub-tab: NOTE You must reboot the Access Point in order for any changes to the Basic IP or DNS Client parameters to take effect.

  • Page 37: Dhcp Server Sub-Tab

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide DHCP Server Sub-tab If your network does not have a DHCP Server, you can configure the AP as a DHCP server to assign dynamic IP addresses to Ethernet nodes and wireless clients. CAUTION Make sure there are no other DHCP servers on the network and do not enable the DHCP server without checking with your network administrator first, as it could disrupt normal network operation.

  • Page 38: Dhcp Relay Agent Sub-Tab

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide You can configure and view the following parameters within the DHCP Server Configuration screen: • Enable DHCP Server: Place a check mark in the box provided to enable DHCP Server functionality. NOTE You cannot enable the DHCP Server functionality unless there is at least one IP Pool Table Entry configured.

  • Page 39: Dhcp Server Ip Address Table

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Figure 4-6 DHCP Relay Agent DHCP Server IP Address Table To add entries to the table of DHCP Relay Agents, click Add in the DHCP Server IP Address Table; the following window is displayed.

  • Page 40: Link Integrity Sub-Tab

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Figure 4-8 DHCP Server IP Address Table - Edit Entries Link Integrity Sub-tab The Link Integrity feature checks the link between the AP and the nodes on the Ethernet backbone. These nodes are listed by IP address in the Link Integrity IP Address Table.

  • Page 41: Interfaces Tab

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Figure 4-9 Link Integrity Configuration Screen Interfaces Tab From the Interfaces tab, you configure the Access Point’s power control settings, wireless interface settings and Ethernet settings. You can configure the operational mode, and configure Transmit Power Control settings. You may also configure a Wireless Distribution System for AP-to-AP communications: –...

  • Page 42: Operational Mode

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Operational Mode You can configure and view the operational mode for the Wireless Interface:: • Operational Mode: the mode of communication between the wireless clients and the Access Point: •...

  • Page 43: Tx Power Control

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide TX Power Control Transmit Power Control uses standard 802.11d frames to control transmit power within an infrastructure BSS. This method of power control is considered to be an interim way of controlling the transmit power of 802.11d enabled clients in lieu of implementation of 802.11h.

  • Page 44: Wireless Interface Sub-Tab (802.11A/B/G Radio)

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Wireless Interface Sub-tab (802.11a/b/g radio) Figure 4-11 Wireless Interface Sub-tab You can configure the following radio parameters for the Wireless interface. • You must reboot the Access Point before any changes to these parameters take effect.Operational Mode: The 802.11a/b/g wireless interface can be configured to operate in the following modes: –...
  • Page 45   Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide • Regulatory Domain: Reports the regulatory domain for which the AP is certified. Not all features or channels are available in all countries. The available regulatory domains include: — FCC - U.S., Canada, Mexico, Argentina, Australia —...

  • Page 46: Dynamic Frequency Selection (Dfs)

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Dynamic Frequency Selection (DFS) AirSPEED AP541 devices sold in Europe use a technique called Dynamic Frequency Selection (DFS) to automatically select an operating channel. During boot-up, the AP scans the available frequency and selects a channel that is free of interference.

  • Page 47: Multicast Rate

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide After wireless service resumes, the AP resumes beaconing, transmitting and receiving frames to/from the wireless interface and bridging the frames between the Ethernet and the wireless interface. Traps Generated During Wireless Service Shutdown (and Resume) The following traps are generated during wireless service shutdown and resume, and are also sent to any configured Syslog server.

  • Page 48: Ethernet Sub-Tab

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide 1 Mbit/s Figure 4-12 1 Mbits/s and 11 Mbits/s Multicast Rates Ethernet Sub-tab Select the desired speed and transmission mode from the drop-down menu. Half-duplex means that only one side can transmit at a time and full-duplex allows both sides to transmit.

  • Page 49: Wireless Distribution System (Wds) Sub-Tab

      Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide Wireless Distribution System (WDS) Sub-tab A Wireless Distribution System (WDS) creates a link between two 802.11a, 802.11b, or 802.11b/g APs over their radio interfaces. This link relays traffic from one AP that does not have Ethernet connectivity to a second AP that has Ethernet connectivity.
  • Page 50   Advanced Configuration SYSTIMAX AirSPEED AP541 User Guide User Guide WDS Setup Procedure NOTE You must disable Auto Channel Select to create a WDS. Each Access Point that is a member of the WDS must have the same Channel setting to communicate with each other. To setup a wireless backbone follow the steps below for each AP that you wish to include in the Wireless Distribution System.
