(Fibre, ADSL/VDSL) follow the steps below:
1. For Fibre Connections
Connect the yellow ethernet
cable from the red WAN Port
of your modem to either
the LAN1 or GE1 Port of
your ONT. Your ONT will
be located on your wall.
(See below for details)
Your Optical Network Terminal (ONT)
This is the under side of your ONT, which will be located on your
wall if you have a fibre network connection.
POTS1
POTS2
TEL
This connects to
your modem.
OR
For ADSL or VDSL Connections
1. Connect the microfilter
to the phone jack
on your wall.
2. Connect the grey
Phone Cable from
the microfilter to
the DSL Port of
your modem.
GE1 This connects to your modem
RESET
GE1
GE3
OR
LAN1
LAN2
LAN3
LAN4
1
Phone Cable
2
WAN Port
GE3
GE4
POWER
POWER RESET WLAN WPS
Make sure this button is pushed
in so that the POWER light at the
front of the ONT shows green.
Microfilter
DSL Port
LED ON/OFF
