Hood Preparation & Installation
CAUTION
At least two installers are required due to the weight
and size of the hood.
1. Remove baffle filter, all packing materials, and
protective film prior to installation. Use caution
during installation to prevent scratches or damage
to the stainless steel.
2. Prepare custom cabinet enclosure by following the
dimensions in FIG. B and the chart below.
3. If ducting vertically, continue to step 4. If ducting
horizontally, remove the motor by (8) screws, knock
out the rear duct 6" hole, orient the motor for
horizontal ducting, and reinstall motor and bracket,
FIG. C, page 14.
4. Install hood into cabinet. FIG D, page 14.
NOTE: Wood blocking may need to be added to
cabinet base if additional support is needed.
5. Secure front panel to cabinet. FIG E, page 14.
6. Finalize electrical and ductwork. Seal ductwork with
certified aluminum duct tape.
7. Switch power on and check for leaks around duct
tape. Test for proper operation.
8. Reinstall filter.
Vortex Use, Care, and Installation Guide
Installation Instructions
Custom Hood
Model Exterior Width
AK9028BS 30 inches
AK9034BS 36 inches
Cut-Out
Width (C)
Model
AK9028BS
26- "
5/8
AK9034BS
*Dimension does not include 3/8" wide flange around hood.
**Assumes backboard thickness of 3/8"
Recommended
Side Panel Thickness:
3/4''
"
1/ 6
Plywood Base
FIG. B
Inside Inside Depth*
(A)
Width*
Without Backboard
28 "
1/2
17 " - 20
1/2
34 "
1/2
Cut-Out
Depth (D)
Without Backboard
10- " 1- "
1/2 3/8
3/8" Wide Flange
(B)
With Backboard**
" 17 " - 20 "
1/2 1/8 1/8
Rear Base
(E)
Depth
With Backboard**
1"
