A
PPLICATION GUIDELINES

MLZ/MLM058-066-076

12
D
IMENSIONS
9.13
7.491 - 7.509
5.24
4.84
34°
7.211 - 7.288
Discharge
port 7/8" ODF
3.63 - 3.70
19.29
1)
19.66
2)
11.28
0.27
Terminal box
Quick connect spade terminals
P terminal box type
FRCC.PC.016.A1.22
4 x Ø 0.75 - 0.78
4.93 9.13
7.491-7.509
73°
31°
45°
Suction port 1"1/8 ODF
1)
2)
Oil sight glass
13.79
Schrader valve
and cap
0.28
1.91
0.74
Mounting grommet
1.16
1.61
Recommended torque for mounting bolts:
100 lbf.in (±10 lbf.in)
Refer to page 36 for overview of shipped mounting accessories
20.34
20.72
MLZ/M058
1)
MLZ/M066-076
2)
All dimensions in Inch
0.06
Ø 0.43
Ø 1.61
5/16" - 18 UNC
self tapping
