P A R T S I N C L U D E D :
Anchor
bracket
I M P O R T A N T
W A R N I N G
AV S - 0 2 1 - W B K 1 - I N S T - A - J U LY 2 0 1 6
Installation Instructions for
AV/VC One Wall Brace Kit
AV S / 0 2 1 / W B K 1
A V S / 0 2 1 / W B K 1
Wall
M8 x 16mm
bracket
•
Note that screen sizes of 65" to 80" may be mounted in dual screen configuration but only
if the AV/VC One is stabilised by securing to the wall or building structure using the
accessory 'AV/VC One Wall Brace Bracket' (Product code: AVS/021/WBK1)
•
It is recommended that screens are removed before moving the AV/VC One unit.
M8 x 20mm
screw x 2
screw x 2
E L E C T R I C A L S A F E T Y
•
Safe installation of electrical equipment is the responsibility of the installer.
•
Colebrook Bosson Saunders recommends that only double-insulated
electrical equipment and cables are installed in AV/VC One unit.
M A I N T E N A N C E A N D I N S P E C T I O N
•
Ensure all screws and fixings are fully tightened and occasionally re-tighten if necessary.
•
Clean with a dampcloth. DO NOT use solvents.
D I S C L A I M E R
As part of Colebrook Bosson Saunders ongoing product improvement
programme, the design of products may change without prior notice
and details may vary from those illustrated.
REFER ALSO TO MAIN
INSTRUCTIONS FOR AV/VC
ONE STAND INSTALLATION
M8 Washer
x 6
M8 Nut x 2
