AVS/021/FB1
Kit (incl Front Panel)
2 people may be
required to mount
screens
P A R T S I N C L U D E D :
Front Box
W A R N I N G
AV S - 0 2 1 - F B 1 - I N S T - A - M AY 2 0 1 6
Installation Instructions
for Front Box Kit (Including front panel)
AV S / 0 2 1 / F B 1
A V S / 0 2 1 / F B 1
Front Panel
4x
Top Cover
Captive Nut x4
E L E C T R I C A L S A F E T Y
•
Safe installation of electrical equipment is the responsibility of the installer.
6x
•
Colebrook Bosson Saunders recommends that only double-insulated
electrical equipment and cables are installed in AV/VC One unit.
M A I N T E N A N C E A N D I N S P E C T I O N
•
Ensure all screws and fixings are fully tightened and occasionally re-tighten if necessary.
•
Clean with a dampcloth. DO NOT use solvents.
D I S C L A I M E R
As part of Colebrook Bosson Saunders ongoing product improvement
programme, the design of products may change without prior notice and
details may vary from those illustrated.
REFER ALSO TO MAIN
INSTALLATION INSTRUCTIONS
FOR AV/VC ONE
Lock Washer x4
4x
6x
4x
Fixing Screw x6
4x
6x
6x
