intro
P A R T S I N C L U D E D :
W A R N I N G
AV S - 0 3 1 - S L F 1 - I N S T - A - N O V 2 0 1 6
Installation Instructions for
AV/VC Intro Shelf Mount
AV S / 0 3 1 / S L F 1
A V S / 0 3 1 / S L F 1
Shelf
M6 Screws x4
REFER ALSO TO MAIN
INSTRUCTIONS FOR AV/VC
INTRO STAND INSTALLATION
Column Brackets x2
Shelf Brackets x2
E L E C T R I C A L S A F E T Y
•
Safe installation of electrical equipment is the responsibility of the installer.
•
Colebrook Bosson Saunders recommends that only double-insulated
electrical equipment and cables are installed in AV/VC Intro unit.
M A I N T E N A N C E A N D I N S P E C T I O N
•
Ensure all screws and fixings are fully tightened and occasionally re-tighten
if necessary.
•
Clean with a damp cloth. DO NOT use solvents.
D I S C L A I M E R
As part of Colebrook Bosson Saunders ongoing product improvement
programme, the design of products may change without prior notice and
details may vary from those illustrated.
M4 Screws x4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Colebrook Bosson Saunders AV/VC Intro AVS/031/SLF1
Summary of Contents for Colebrook Bosson Saunders AV/VC Intro AVS/031/SLF1
- Page 1 Clean with a damp cloth. DO NOT use solvents. D I S C L A I M E R As part of Colebrook Bosson Saunders ongoing product improvement programme, the design of products may change without prior notice and details may vary from those illustrated.
- Page 2 Unlock and remove back panel...
- Page 3 Install column brackets 2 . 1 P O S I T I O N C O L U M N B R A C K E T O N T H E I N S I D E O F T H E C O L U M N 2 .
- Page 4 Install shelf mount brackets 3 . 1 3 . 2 F I X B R A C K E T T O S H E L F U S I N G I N S T A L L S E C O N D B R A C K E T T O C O L U M N 2 X M 6 S C R E W S Consider shelf mounting height.
-
Page 5: Cable Management (Optional)
Cable management (optional) For a tidy installation, feed equipment cables up behind screen mount and through the cable management hole. - Page 6 Install back panel...
- Page 7 Adjusting shelf height once installed 6 . 1 6 . 2 L I F T T H E S H E L F U P W A R D S T O D I S E N G A G E P U S H S H E L F T O W A R D S T H E C O L U M N A N D T H E H O O K S F R O M T H E C O L U M N R A I S E O R L O W E R S H E L F T O T H E R E Q U I R E D...
