Getting Started; Unpacking; Verifying The Contents Of Your Shipment; Setting Up And Configuring The Sc5506A - SIGNALCORE SC5506A Operating & Programming Manual

G
E T T I N G

Unpacking

All SignalCore products ship in antistatic packaging (bags) to prevent damage from electrostatic discharge
(ESD). Under certain conditions, an ESD event can instantly and permanently damage several of the
components found in SignalCore products. Therefore, to avoid damage when handling any SignalCore
hardware, you must take the following precautions:
•
Ground yourself using a grounding strap or by touching a grounded metal object.
•
Touch the antistatic bag to a grounded metal object before removing the hardware
from its packaging.
!
•
Never touch exposed signal pins. Due to the inherent performance degradation caused
by ESD protection circuits in the RF path, the device has minimal ESD protection
against direct injection of ESD into the RF signal pins.
•
When not in use, store all SignalCore products in their original antistatic bags.
Remove the product from its packaging and inspect it for loose components or any signs of damage. Notify
SignalCore immediately if the product appears damaged in any way.

Verifying the Contents of your Shipment

Verify that your SC5506A kit contains the following items:
Quantity Item
1 SC5506A Dual Channel RF Signal Source
1 Software Installation USB Flash Drive (may be combined with other products onto a single drive)

Setting Up and Configuring the SC5506A

The SC5506A is a core module-based RF signal source with all I/O connections and indicators located on
the front face of the module as shown in Figure 1. Each location is discussed in further detail below.
Figure 1. Front view of the SC5506A showing user I/O locations.
