Vegetable Pan; Lighted Vegetable Drawer Shelf; Adjustable Shelves - Monogram ZIC303NP II Series Owner's Manual

FEATURES - BOTTOM FREEZER ONLY

VEGETABLE PAN

The Vegetable Pan in the fresh-food section of the
refrigerator has LED strip lighting above the drawer.
There are adjustable dividers with several different position
options. The divider is held in place by a tab located under
the handle, a slot located on the back wall and a stabilizing
rib on the bottom of the drawer for each position.
To change the divider position:
1. Pull up on the back of the divider to release it from the
slot in the back and off of the tab in the front.
2. Slide the divider into a new location, making sure it
seats into the rib on the bottom of the drawer.
3. Pull up on the back of the divider to locate the front
under the tab at the new location.
4. Push down on the back of the divider to seat
it into the slot at the new location.

LIGHTED VEGETABLE DRAWER SHELF

The lighted vegetable drawer shelf provides lighting for the
lower compartments. The lights are recessed into the shelf
to illuminate the drawers below.
To remove the shelf:
1. Lift the shelf and carefully pull forward to expose
the wires.
2. Unplug the shelf and carefully remove it from
the refrigerator.
To replace the shelf:
1. Carefully set the shelf onto the side rails, leaving the
plug exposed.
2. Plug the shelf into the refrigerator.
3. Carefully slide the shelf into place.

ADJUSTABLE SHELVES

Tempered glass shelves in the fresh food section enable
you to make efficient shelf arrangements to fit your family's
food storage needs.
To adjust shelves: Tilt the shelf up at the front and slide it
up or down along the back wall to the placement you want.
Handle glass shelves carefully. Rough handling of
tempered glass can cause it to shatter.
To remove shelves:
NOTE: To remove a shelf, all shelves under it must first be
removed.
1. Remove any food from the shelf.
2. Remove covers at the bottom of each track.
3. Tilt the first shelf up at the front.
4. Slide the shelf down along the back wall until you reach
the bottom where the notch is located. Slide the shelf
through the notch.
10
Ribs
5. Repeat for removing the other shelves.
To replace shelves:
Replace shelves by perform steps 1 through 4 in reverse.
Front
Tab
Lighted
Vegetable
Drawer Shelf
LED lights are located
under the shelf at the front
Lift shelf and
pull forward
Cover
49-1000500 Rev. 1
Slot
Back
