Vegetable pan

The Vegetable Pan in the fresh-food section
of the refrigerator has LED strip lighting above
the drawer.
There are adjustable dividers with several
different position options. The divider is held in
place by a tab located under the handle, a slot
located on the back wall and a stabilizing rib on
the bottom of the drawer for each position.
To change the divider position:
1. Pull up on the back of the divider to release
2. Slide the divider into a new location, making
3. Pull up on the back of the divider to locate
Lighted
The lighted vegetable drawer shelf provides
lighting for the lower compartments. The lights
vegetable
are recessed into the shelf to illuminate the
drawer shelf
drawers below.
To remove the shelf:
1. Lift the shelf and carefully pull forward to
2. Unplug the shelf and carefully remove it from
To replace the shelf:
1. Carefully set the shelf onto the side rails,
2. Plug the shelf into the refrigerator.
3. Carefully slide the shelf into place.
Adjustable
Tempered glass shelves in the fresh food section
enable you to make efficient shelf arrangements

shelves

to fit your family's food storage needs.
To adjust shelves: Tilt the shelf up at the front
and slide it up or down along the back wall to the
placement you want.
Handle glass shelves carefully. Rough handling
of tempered glass can cause it to shatter.
To remove shelves:
NOTE: To remove a shelf, all shelves under it must
first be removed.
1. Remove any food from the shelf
2. Remove covers at the bottom of each track.
3. Tilt the first shelf up at the front.
4. Slide the shelf down along the back wall until
10
it from the slot in the back and off of the tab
in the front.
sure it seats into the rib on the bottom of
the drawer.
the front under the tab at the new location.
expose the wires.
the refrigerator.
leaving the plug exposed.
you reach the bottom where the notch is
located. Slide the shelf through the notch.
Vegetable Pan/Shelves
30" Bottom-Freezer
Ribs
4. Push down on the back of the divider to seat
it into the slot at the new location.
LED lights are located
under the shelf at the front
Lift shelf and
pull forward
5. Repeat for removing the other shelves.
To replace shelves:
Replace shelves by perform steps 1 through 4
in reverse.
Front
Slot
Tab
Back
Lighted
Vegetable
Drawer Shelf
Cover
