- Page 1 TrueNAS M-Series Unified Storage Array ® Basic Setup Guide May 2018 Edition...
- Page 2 If there is any shipping damage or any parts are missing, please take photos and contact iXsystems support immediately at support@iXsystems.com or 1-855-GREP4-iX (1-855-473-7449) or 1-408-943-4100.
- Page 3 (POST) and turns off during normal operation. It turns on if the TrueNAS software issues an alert (https://support.ixsystems.com/truenasguide/tn_options.html#alert). The M-Series contains one or two storage controllers in an over-and-under configuration. The connectors and features on each storage controller are:...
- Page 4 1.2 ES24 and M-Series Rail Kit Assembly 1.2.1 Remove Cabinet Rails from Rack Rails Extend the cabinet rail until it stops. To remove the cabinet rail, press the white release tab to the right while pulling the cabinet rail. 1.2.2 Mount Cabinet Rails The cabinet rails are mounted on both sides of the system cabinet.
- Page 5 1.2.4 Mount the Unit in the Rack Caution: Two people are required to safely lift the chassis for rack installation or removal. Do not install drives until after the chassis has been installed in the rack, and remove all drives before removing the chassis from the rack. Pull the front rack rail forward until it stops.
- Page 6 1.3 Install Drive Trays Drive trays are used to mount drives in the array. Drive trays are installed in drive bays in the chassis. Each drive bay in the chassis has two indicator LEDs to the right of the tray. The status LED is blue when the drive is active, and the fault LED is red if a fault has occurred.
- Page 7 2 User Guide ® ® The TrueNAS User Guide with complete configuration instructions is available by clicking Guide in the TrueNAS user in- terface or at https://support.ixsystems.com/truenasguide/truenas.html. 3 Contacting iXsystems For assistance, please contact iX Support: Contact Method Contact Options https://support.ixsystems.com Email support@iXsystems.com...
