- Page 1 i-vac 9B Battery powered freedom User manual i-team Professional b.v. Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands Telephone: +31402662400 Email: hello@i-teamglobal.com Internet: www.i-teamglobal.com...
- Page 2 Original user manual, written in the English Language Future Cleaning Technologies B.V. Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands Telephone: +31402662400 Email: hello@i-teamglobal.com Internet: www.i-teamglobal.com Model: C9B Date: 11/05/2020 Product code: C9B.I-V.0000B Version: v.1.0...
-
Page 3: Preface
Become familiar with the correct operation and maintenance procedures. Store the manual in a safe place. The manual is an essential part of the i-vac 9B and must be handed over to the new owner upon resale or exchange. Each i-vac 9B has a unique identification number that can be found at the bottom of the can. -
Page 4: Reading Guide
Reading guide The following symbols and terms are used throughout this manual to alert the reader to safety issues and important information: Symbol Term Explanation WARNING Indicates a hazardous situation which, if the safety instructions are not followed, can lead to injuries of the operator or bystanders, light and/or moderate damage to the product or the environment. -
Page 5: Table Of Contents
Content Preface ..................................3 Purpose of the user manual ............................ 3 Target audience ..............................3 Operators of the i-vac 9B ............................3 Reading guide ................................4 Introduction ..............................7 Intended use of the product ........................7 Non-intended use of the product ......................8 Lifespan .............................. - Page 6 7.1.1 Clean the machine ........................... 27 7.1.2 Clean the hose and wand ........................ 27 Replacing the filters ..........................28 7.2.1 Replacing the cassette filter ......................28 7.2.2 Replacing the motor filter ....................... 29 Brush and tool condition ........................30 Damaged or worn parts ........................30 Maintenance frequency ........................
-
Page 7: Introduction
1 Introduction The i-vac 9B® is an easy and safe machine to use. This manual helps you get started and explains the operation and maintenance procedure. The i-vac 9B is battery-operated. The batteries used in the i-vac 9B are the same as in a variety of other battery powered i-team products. -
Page 8: Non-Intended Use Of The Product
Keep the i-vac 9B and the accessories clean. In order to use the i-vac 9B on different types of surfaces, extra tools are provided. These tools are easy to replace. Select the right tool for each job, see Figure 2. -
Page 9: Lifespan
• big pieces of glass, plastic or wood. 1.3 Lifespan For a proper functioning and a long lifespan of the i-vac 9B, it is important to follow the recommended maintenance frequency mentioned in this manual, see section 7.5. 1.4 Modifications It is not permitted to make modifications to the design of the i-vac 9B without consultation and permission from the manufacturer. -
Page 10: Specifications
1.5 Specifications Figure 3 Body size: 450 x 450 x 410 mm Carrying weight: 7 kg Hose length: 250 cm Capacity: Noise level: 58 dB(A) Diameter of tools: 32 mm Water lift / suction: 1300 mm Air flow: 24,7 L / sec Application: Indoor, dry Battery slot capacity:... -
Page 11: Warranty
The i-vac 9B® should only be operated with the materials supplied. Using alternative supplies may cause damage to the i-vac 9B and may cause a risk to the operator. The use of alternative supplies or not following the instructions in this manual voids the manufacturer's warranty. The warranty period is 1 year. -
Page 12: Description
2 Description The body of the i-vac 9B® is made of durable and impact resistant material. The hose is extra long so you can reach out to difficult spots. The i-vac 9B can be combined with an optional i-brush®. This extra floor tool simultaneously agitates the carpet and removes dirt and dust. -
Page 13: Explanation Led Indicators
LED works. The red LED will also light up when the batteries are almost empty. 2. A vacuum function LED. The vacuum function LED flashes when the ON/OFF button is turned on. When the i-vac 9B® is on full power it is permanent on. Figure 6... -
Page 14: Safety
DO NOT use the i-vac 9B on damp or wet surfaces. This will cause damage to the i-vac 9B and is dangerous to the user. The damage caused by the use on a wet surface is not covered under the warranty. -
Page 15: Transport And Storage
9B is stored for a longer period, remove the batteries. See section 6.2.2; • before you transport the i-vac 9B, remove the batteries. See section 6.2.2; • before you use the i-vac 9B again, make sure the batteries are loaded, see the user manual of the i-charge 9®. -
Page 16: Assembly And Installation
The i-vac 9B® does not require much assembly. The machine comes with 3 additional tools for vacuuming different types of surfaces. 5.1 Unboxing The i-vac 9B is packed in 1 box. The batteries and the battery charger must be ordered separately. Figure 7 Legend... -
Page 17: Assembly
5.2 Assembly 1. Insert the hose (Figure 8, pos 1) into the hose connector (Figure 8, pos 6). 2. Turn the hose clockwise to lock it into place. 3. Insert the hose into the wand (Figure 8, pos 2). 4. Attach the standard floor tool (Figure 8, pos 5) on the wide end of the wand. 5. -
Page 18: Replacing The Dust Bag
5.3 Replacing the dust bag Check the dust bag every week and replace it if it is full. Only use original i-team dust bags. Make sure that the hose is removed from the i-vac 9B® before removing the dust bag. You cannot remove the dust bag with the hose in place. - Page 19 6. Turn the hose (Figure 11, pos 4) counterclockwise and remove it from the hose connector. 7. Pull the cardboard tag (Figure 11, pos 2) to seal the dust bag. 8. Fold the ends of the dust bag (Figure 11, pos 1) towards each other.
- Page 20 14. Fasten the latches (Figure 14, pos 2). 15. Replace the batteries. See section 6.1.2. Figure 14 ATTENTION Make sure that the head is correctly placed on the can, otherwise false air may be sucked in and this affects the performance of the i-vac 9B®.
-
Page 21: Operation
1. Check the i-vac 9B® for damage or defects. 2. Check that the dust bag is placed in the i-vac 9B. See also section 5.3. 3. Make sure you have the correct tool for the intended purpose. See also Figure 2. -
Page 22: Insert And Check The Batteries
4. Press the ON/OFF switch (Figure 17, pos 1) to turn off the i-vac 9B. Figure 17 TIP: It is not recommended to use the batteries when charged less than 40%. The i-vac 9B can operate on a single battery. -
Page 23: Normal Operation
6.2 Normal operation 1. Press the ON/OFF switch (Figure 18, pos 1) to start the i-vac 9B®. The vacuum function LED will go on. 2. Take the wand (Figure 18, pos 2) from the holder. 3. Start vacuuming. Figure 18 6.2.1 After normal operation... -
Page 24: Remove The Batteries
6.2.2 Remove the batteries 1. Press the plastic clips of the battery (Figure 19, pos 1) slightly towards each other. 2. Pull out the battery. 3. Place the batteries in the charger for next use. Figure 19... -
Page 25: Operation With I-Brush
3. Insert the hose of the i-brush (Figure 20, pos 4) into the hose connector (Figure 20, pos 2). 4. Turn the hose clockwise to lock it into place. 5. Push the plug from the i-brush (Figure 20, pos 5) onto the connector on the i-vac 9B (Figure 20, pos 1) and tighten the ring of the plug. -
Page 26: Remove The Batteries
6.3.2 Remove the batteries 1. Press the plastic clips of the battery (Figure 21, pos 1) slightly towards each other. 2. Pull out the battery. 3. Place the batteries in the charger for next use. Figure 21... -
Page 27: Maintenance
Maintenance that is not described in this manual should be done by your i-team partner. Please make sure to have the model and serial number of the i-vac 9B available when you call a partner. For more information please fill out the contact form on www.i-teamglobal.com. -
Page 28: Replacing The Filters
7.2.1 Replacing the cassette filter CAUTION When you place the new cassette filter into the head of the i-vac 9B®, make sure the arrows on the filter point upwards. 1. Turn the yellow locking disc (Figure 22, pos 1) up. -
Page 29: Replacing The Motor Filter
7.2.2 Replacing the motor filter 1. Turn off the i-vac 9B® with the ON/OFF switch (Figure 23, pos 1). 2. Remove the batteries. See section 6.2.2. 3. Release the latches (Figure 23, pos 2). 4. Lift the head by the handle (Figure 23, pos 3). -
Page 30: Brush And Tool Condition
Check the condition of the brush or tool before use. Only change the brush or tool when the machine is turned off. 7.4 Damaged or worn parts Damaged or worn parts need to be replaced immediately. Contact your local i-team Global partner or visit www.i-teamglobal.com for more information. -
Page 31: Maintenance Frequency
7.5 Maintenance frequency Make sure that routine and preventive maintenance is carried out periodically to ensure safe operation. Failure to carry out maintenance as necessary may cause damage to the i-vac 9B® and may cause a risk to the operator. -
Page 32: Trouble Shooting
Wait approximately 30 minutes. Start the i-vac 9B by pushing the "ON" button. Little suction power Filter bag full Turn off the i-vac 9B and replace filter bag. Hose not well attached Turn off the i-vac 9B and reattach hose. Hose blocked Turn off the i-vac 9B and remove blockage. -
Page 33: Decommissioning And Disposal
It is the responsibility of the i-vac 9B® owner to dispose of the product responsibly. At the end-of-life the i-vac 9B still contains valuable resources and needs to be disposed of according to your local laws and regulations regarding recycling of electrical equipment. -
Page 34: Attachments
10 Attachments 10.1 CE Certificate... - Page 35 This document is part of the technical file of the i-vac 9B® and will be available upon request.
