Table of Contents

Table of Contents ................................................................ 2
Safety Information ............................................................... 2
Warranty ............................................................................... 3
Pre-Installation .................................................................... 3
Installation ............................................................................ 6

Safety Information

READ AND SAVE THESE INSTRUCTIONS.
1. To reduce the risk of electric shock, ensure the electricity has
been turned off at the circuit breaker or fuse box before you
begin.
All wiring must be in accordance with the National Electrical
2.
Code ANSI/NFPA 70 and local electrical codes. Electrical
installation should be performed by a qualified licensed
electrician.
The outlet box and support structure must be securely mounted
3.
and capable of reliably supporting 35 lbs. (15.9 kg). Use only UL
Listed outlet boxes marked "Acceptable for Fan Support of 35
lbs. (15.9 kg) or less."
Do not operate the reversing switch while the fan blades are in
4.
motion. You must turn the fan off and stop the blades before
you reverse the blade direction.
5. Do not place objects in the path of the blades.
6. After making electrical connections, spliced conductors
should be turned upward and pushed carefully up into the
outlet box. The wires should be spread apart with the
grounded conductor and the equipment-grounding conductor
on one side of the outlet box and ungrounded conductor on
the other side of the outlet box.
7.
All setscrews must be checked and retightened where
necessary before installation.
Assembly ............................................................................ 7
Operation ........................................................................... 15
Care and Cleaning ............................................................. 15
Troubleshooting ................................................................. 16
FCC Statement . ................................................................... 17
WARNING: To reduce the risk of personal injury, do not
bend the blade brackets when installing the brackets
balancing the blades, or cleaning the fan. Do not insert
foreign objects in between rotating fan blades.
WARNING:
or personal injury, mount to outlet box marked
"acceptable for fan support of 35 lbs. (15.9Kg)
or less" and use screws provided with the outlet box.
WARNING: To avoid possible electrical shock,
turn the electricity off at the main fuse box before
wiring. If you feel you do not have enough electrical
wiring knowledge or experience, contact a licensed
electrician.
WARNING:
shock, do not use this fan with any solid-state speed
control device.
CAUTION: To reduce the risk of personal injury,
use only the screws provided with the outlet box.
CAUTION: To avoid personal injury or damage to the fan
and other items, use caution when working around or
cleaning the fan.
CAUTION:
of 7 ft (2.1 m) clearance from the trailing edge of the
blades to the floor.
CAUTION:
approved by the party responsible for compliance could
void the user's authority to operate the equipment.
2
To reduce the risk of fire, electric shock
To reduce the risk of fire or electric
The fan must be mounted with a minimum
Changes or modifications not expressly
