- 1 CONTENTS 695468 Frosted Glass
- 2 CONTENTS 695469 Magnetic Glass
- 3 Use a 9/32" Drill Bit and Drill (8) Holes 11/2" Deep.
- 4 Attach Standoffs to Plastic Anchors Using the (8) Phillips Pan Head Screws Provided.
- 5 Insert Concealed Tray Behind Glassboard at Bottom Right Corner before Securing the Cap Screw.
- 6 Attach Glassboard to Standoffs as Shown.
- 7 Directives D'assemblage
- Download this manual
globalindustrial.ca
Assembly Instructions
Customer Service
US: 1-800-645-2986
WARNING:
Use appropriate hardware
when mounting to concrete.
Use 3 people to install.
Use caution when lifting
heavy board.
1
64"
32"
2
Use a 9/32" drill bit and
drill (8) holes 1
Instrucciones de Ensamblaje
Servicio de atención al Cliente
México: 01.800.681.6940
Glass Eraser Board 96"W x 48"H
Models 695468/695469
44"
96"
" deep.
1 /2
Distribucion Industrial Globales S DE RL DE CF
Determine the mounting
location on the wall and
mark hole locations using
the assigned dimensions
and a level.
1
Service à la clientèle
Canada: 888-645-2986
CONTENTS 695468 Frosted Glass
Ref.
Qty.
Description
1
1
Glassboard
2
1
Concealed Tray
H1
8
Plastic Anchor
H2
8
Standoff
#6 Phillips Pan Head
H3
8
Screw 1
" Lg.
1
/
2
H4
8
Rubber Washer
H5
8
Cap Screw
CONTENTS 695469 Magnetic Glass
Ref.
Qty.
Description
1
1
Glassboard
2
1
Concealed Tray
4
Magnet
1
Magnet Eraser Cloth
H1
8
Plastic Anchor
H2
8
Standoff
#6 Phillips Pan Head
H3
8
Screw 1
" Lg.
1
/
2
H4
8
Rubber Washer
H5
8
Cap Screw
3
H1
Insert the (8) plastic
anchors flush to the wall.
022516
