Operation

1. Before powering on the robot make sure it is up on blocks so the wheels can spin freely. Occasionally
some or all of the wheels start as soon as the motor controller gets power. In this case the settings of the
motor controller need to be changed.
2. Make sure to use the correct DIP switch settings. If using a Sabertooth motor controller in R/C mode
switch 1 should be DOWN (closest to the number) and all other switches should be UP. If using a different
mode see the manual for the motor controller you are using on Dimension Engineering's website.
Binding a Spektrum Remote
3. Insert the bind plug into the receiver and power on the robot.
4. While pressing the Bind button, power on the transmitter.
5. Release the Bind button after the receiver's LED stays illuminated. This indicates the receiver is bound to
the transmitter.
6. While the robot and transmitter are still powered on, remove the bind plug from the receiver.
7. If the wheel aren't moving as desired, it may be necessary to swap the Alieron and Elevator plugs or to
reverse the channels on the transmitter. To reverse channels see the instructions for "Servo Reversing" in
the Spektrum documentation.

General Terms

1. SuperDroid Robots, Inc is not responsible for special incidental or consequential damages resulting from any
warranty or under any legal theory, including, but not limited to lost profits, downtime, goodwill, damage to,
or replacement equipment or property, or any cost of recovering, reprogramming, or reproducing any data
stored. ANY LIABILITY SHALL BE LIMITED TO REPLACEMENT OF DEFECTIVE PARTS. SuperDroid Robots, Inc. is
further not responsible for any personal damages, including, but not limited to bodily and health damages
resulting from any use of our products.
2. SuperDroid Robots, Inc. makes no representations as to the fitness of its products for specific uses. ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS HEREBY
EXCLUDED.
3. Agreements shall be construed in accordance with the laws of the State of North Carolina, and the rights and
obligations created hereby shall be governed by the laws of North Carolina.
4. In the event a dispute or controversy arises, such dispute or controversy (including claims of default) shall be
brought in the courts of Wake County, North Carolina and the plaintiff hereby agrees to this choice of venue.
