- Page 1 TP-196-006 WC1500-DM6 6WD ATR PLATFORM SuperDroid Robots, Inc 919.557.9162 SDR@SDRobots.com 224 Technology Park Lane, Fuquay Varina, NC 27526 Revised Sep 9, 2020...
- Page 2 TABLE OF CONTENTS TABLE OF CONTENTS................................2 LEGAL INFORMATION ................................3 SAFETY GUIDE ..................................4 Safety Precautions ................................. 4 SECTION 1 - ASSEMBLY ............................... 5 Mechanical Assembly..............................5 SECTION 1 - ASSEMBLY CONTINUED ........................... 6 SECTION 2 - ELECTRICAL ASSEMBLY........................... 7 Resources ..................................
- Page 3 2. SuperDroid Robots, Inc. makes no representations as to the fitness of its products for specific uses. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS HEREBY EXCLUDED.
- Page 4 SAFETY GUIDE Thank you for purchasing this product! WARNING - Before using, read this manual to ensure correct usage and operation. After reading, store in a safe place for future reference. Incorrect handling of this robot could result in personal injury or physical damage. The manufacturer assumes no responsibility for any damage caused by mishandling that is beyond normal usage defined in these manuals of this product.
- Page 5 SECTION 1 - ASSEMBLY Mechanical Assembly NOTE Your robot may come in a crate or carry case. As you unpack your robot, note how everything fits so you can store your platform. 1. Before starting the assembly of the robot, be sure to follow the instructions to remove the brake from the back of the motors. The brake is engaged by default.
- Page 6 SECTION 1 - ASSEMBLY CONTINUED 5. Install cord grips for the motor cables to enter the chassis. The cord grip has a nut that turns off the back end of the grip housing (Figure 5A) . Remove the cord grip nut and insert cord grip into the chassis holes located near the motor (Figure 5B).
- Page 7 SECTION 2 - ELECTRICAL ASSEMBLY Resources NOTE Never charge batteries unattended. Regularly charge batteries to prevent levels from dropping below point of recovery. http:/ /www.superdroidrobots.com/terms_batteries.html For electrical assembly locate the Schematic labeled ‘Vectoring Robot’ on our resources page linked below. Electrical Assembly Schematics For additional support on wiring, soldering, and crimping, please visit the following support pages.
- Page 8 CONNECT WITH US ON SOCIAL MEDIA TAG US AND SHARE YOUR ROBOT EXPERIENCE! SDRROBOTS SUPERDROIDROBOTS SDROBOTS SUPERDROIDROBOTS SUPERDROIDROBOTS SCAN THE QR CODE TO VISIT US AT SUPERDROIDROBOTS.COM...
