Suspension Mounting - ETI Solid State Lighting 56567241 Use And Care Manual

Lens
A
Wire Cover
Reconnect the terminal ground wire to the wire
10a
cover. Reattach the wire cover to the fixture.

SuSPeNSION MOuNTINg

Installing contractor is responsible for determining best installation method for desired location
and selecting the appropriate mounting hardware.
nOTe: UL LISTED: CCN:FKAV/7 TYPE: 1/2 FOR THREADED COUPLER.
Drywall
M
If mounting to drywall: Drill two 1/4in. holes in the ceiling. Fasten the toggle bolt
5b
(not included) into the butterfly nut (not included) before inserting the flaps of the
toggle bolt into the ceiling.
Tighten the toggle bolt and make sure the toggle bolt is secure.
If mounting to wood: Drill two 1/16in. pilot holes in the ceiling.
Fasten the combo wood-machine (not included) end into the hook screw (not
included). Tighten the hook screw and make sure it is secure.
If using the Stem Mounting Kit that is sold separately, see the Stem Mounting
Installation section for installation instructions.
nOTe: Distance between 2 holes is 32.9in.
M
J I
Knock Out
K
Hole
L
Wire
Connectors
Feed conduit (not included) and wires from electrical box
9b
through the mounting plate (not included) and then through
the knock out hole and use the nut (not included) to secure
the conduit to the fixture. Use the mounting screws (not
included) to secure the mounting plate to the electrical box.
Make the electrical connections by inserting the wire into
10b
the respective wire connector:
• Black wire to black wire.
• White wire to white wire.
• Green wire to ground wire.
• If a 0-10v dimming circuit is available, connect purple
wire to purple wire and gray wire to gray wire.
Reconnect the terminal ground wire to the wire cover.
11b
Reattach the wire cover to the fixture and make sure to
tuck all of the wires inside the wire cover.
Terminal Ground Wire
Close the lens cover.
11a
Wood
M
A
A
Wire Cover
A
Lens
Hang the mounting chains over the hooks.
6b
Attach the V clip chains to both ends of the fixture and close the hooks
7b
with pliers.
Connect the mounting chains to the V clip chains and make sure the
8b
connections are secure.
End Caps
Lens
Close the lens cover.
14b
Move the locks to the lock position
15b
on both ends of the fixture.
Reattach the end caps.
16b
End Cap
A
Move the locks to the lock position on both ends of
12a
the fixture.
Reattach the end caps.
13a
Restore power to the electrical box. Turn the light
14a
switch on to activate the fixture.
Turn the light switch off and back on again to activate
the direct light only.
Turn the light switch off and back on again to activate
the indirect light only.
nOTe: To change between light modes, the light
switch has to be turned off and on within 3 seconds.
M
F
G
Restore power to the electrical box. Turn the light
17b
switch on to activate the fixture.
Turn the light switch off and back on again to activate
the direct light only.
Turn the light switch off and back on again to activate
the indirect light only.
nOTe: To change between light modes, the light
switch has to be turned off and on within 3 seconds.
End Cap
