PSA-37XP Spectrum Analyzer
Features:
• Display: 5.7" High Contrast 1/4 VGA LCD
• Memories: 50 locations of system memory
• Input Connectors: Band 1 & 2: BNC
• Adapters Included: N—BNC and BNC—F
• LNA/LNB Power: 18V or 13V Selectable
• ReadOut: KU-Band Offsets
• Calibrated RSSI Meter: 80dB of range on receiver side., -40dBm to -120dBm
Frequency:
• Frequency Range:
• Frequency Accuracy: ±100kHz
• Display: On Screen
• IF Frequency: Receiver sensitivity. Frequency range limited to bandwidth of current set receive
frequency, ±10kHz. 1Hz and 10Hz resolutions
General:
• Battery life: 3 hours per battery pack.
• Controls: Rotary Tuning
• RS232 Control: Future Expansion Plans for Serial interface providing external function control
• Primary Power: 100-240 VAC, .6A, 50/60Hz. Built-in 3 hour battery pack (holds 1 additional
battery packs for 6 hour battery life)
• Stand: Bottom mounted aluminum feet attached
• Supplied Accessories: 110 VAC EIA power cord, whip antenna, one BP3010 Li-Ion battery
• Case color: AVCOM green wet coat
• Dimensions: 11.5"W x 5.5"H x 13.5"D
• Weight: 12lbs
Band 3 & 4: N
28
(specifications)
