Operation Menu: 0 - AVCOM PSA-37XP Owner's Manual

MENU STRUCTURE REFERENCE

OPERATION MENU: 0

Button Label
M next
menu m0:
1 traceA->B
2 hide B / view B
3 hide A / view A
4 PeakHold
persistent—unlimited—short—until f3 hit
5 disp
line UP
6 disp
line DOWN
7 disp
line ctrl
off—course—fine
Description
Changes to menu 1
Freezes the current trace to the background
Removes background trace / Displays last background
trace.
Removes active trace from the display / Shows the
active trace on the display.
Causes the active display to hold the peak of the trace
for a set amount of time.
Adjusts the user controlled marker for dB level UP 2dB
Adjusts the user controlled marker for dB level DOWN
2dB
Display line OFF
Course—Adjusts the display line by 2 dB steps
Fine—Adjusts the display line by 1 dB steps
18
