O V E R V I E W
Improved Performance & Specifications
I M P R O V E D P E R F O R M A N C E &
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S P E C I F I C A T I O N S
The new SNG-2500C was designed with excellent frequency and
amplitude accuracy as well as a wide variety of resolution bandwidth
selections ranging from 10kHz to 1MHz. These features enable you
to view and monitor small TT&C and data carriers found in many
satellite communications markets today. The front panel provides
independent control of Frequency & Span (with settings for Fine,
Medium and Coarse), enabling you to dial into the carrier and
control the display as needed.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
V E R S A T I L E G R A P H I C A L U S E R I N T E R F A C E
The SNG-2500C can be monitored and controlled both locally from
the front panel with the color LCD or remotely using the Avcom
Graphical User Interface (GUI). Connecting via either the serial port
or Ethernet port, the remote GUI enables remote monitoring and
control from anywhere in the world via the Internet. If the SNG-
2500C is used in a SNG truck with a high speed cellular broadband
card, an inexperienced operator can get assistance (in the form of
remote monitoring and control) from anywhere in the world.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
F E A T U R E S
• High Resolution Full VGA Color Display
• Fits into Tektronix 1700 Series Dual Mount tub designed for satellite news
gathering market
• Dual Wideband Switched Inputs; 4 and 6 inputs available
• DSP Technology enables refresh rates up to 13/sec
• Digital Tuning for Excellent Frequency Accuracy
• 4 Resolution Bandwidth Selections
• Ethernet & Serial Communications for Full Remote Control Capability
• User Friendly and Intuitive GUI
Revision 001 SNG-2500C User's Guide
1-2
