AVCOM PSA-37XP Owner's Manual page 20

MENU STRUCTURE REFERENCE
OPERATION MENU: 2
Button Label
M next
menu m2:
1 show dBm
2 show dBmv
3 mode dB
normal / hidden / adding X / hiding +X
4 grids ctrl
5 disp
line UP
6 disp
line DOWN
7 disp
line ctrl
Description
Changes to menu 3
Default display of reading on the right of the analyzer
screen
Changes right display to dBmv for specific applications
Determines display and value displayed in dB on right
of analyzer screen
Adding X and hiding +X show the values with X Offset
as entered in STARTUP MENU:4
Toggles Grid display ON/OFF
Adjusts the user controlled marker for dB level UP 2dB
Adjusts the user controlled marker for dB level DOWN
2dB
Display line OFF
Course—Adjusts the display line by 2 dB steps
Fine—Adjusts the display line by 1 dB steps
20
