This equipment is for use in a restricted access area. Warning Ensure power is disconnected from the AX11 before servicing the product or connecting/disconnecting peripherals. Document revision V1.0 Levels of Access Control •...
M4 screw. Required Network Settings An Ethernet connection with DHCP must be used to connect the AX11 to the Local Area Network (LAN). You also need to configure firewall settings to communicate with the AX11. • TCP port 443 •...
Inputs 3 - 16 omitted from diagram, as wiring is identical for all inputs. Relay Outputs AX11 comes equipped with 16 Form C relays that can be driven dry. Max DC load: 24V @ 1A, Max DC current = 1A, Max DC voltage = 60VDC.
Installation Connecting an Output Warning Ensure power is disconnected from the AX11 before plugging in or unplugging any of the terminal blocks. Failure to do so may damage the AX11 Wiring a Powered Lock AX11 Relay Output Access Power Controller Lock It is recommended to interface with an Access Power Controller (APC) to provide power to the accessory.
Wiring a Verkada or Wiegand Reader The AX11 is rated to power readers at 12V up to 250mA via the + Vin and - GND connection. The drain wire of the shielded cable should be secured to nearest AX11 chassis ground.
Battery Leads Connect Connect the AX11 to your network using either of the Ethernet ports located at the bottom of the controller. If you are installing multiple controllers, you can connect up to 4 additional controllers via the spare Ethernet port on each controller.
