  • Page 1 For Android Enterprise Mobility PM75 User Manual Copyright © 2006 – 2021 Google, Android, Google Play and other marks are Point Mobile Co., Ltd. All rights reserved trademarks of Google LLC.

  • Page 2: Instruction

    PM75 Android 11 User Manua l Instruction This manual provides information about basic features and using the PM75. Please read this manual carefully before using your handy payment device and peripherals to ensure safe and proper use. Note: Screenshots in this manual may differ from actual screens.

  • Page 3: Pm75 Skus

    N3601 SR Extended Wi-Fi/BT LTE, SKU5 PM75G6Q03BJE0C GPS, 3G/32G N6603 SR Standard Wi-Fi/BT LTE, SKU6 PM75G6V03DJE0C GPS, 4G/64G N3601 SR Standard Wi-Fi/BT LTE, SKU7 PM75G6Q03DJE0C GPS, 4G/64G N6603 SR Standard Wi-Fi/BT © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 4: Table Of Contents

    Controlling the touch screen ....................22 System navigation ......................24 LEARNING THE BASICS ..................26 Setup Wizard ......................... 26 Home Screen ......................... 27 Status bar ........................... 28 Notification panel ........................ 29 © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 5 Program Buttons ........................47 CAMERA ........................ 49 SCANNER ....................... 50 Turn on / off the Scanner ....................... 50 ScanSettings .......................... 51 Basic ........................... 51 Options ..........................52 Notification .......................... 53 Wedge ..........................54 © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 6 Check Device Health ......................70 OS Update ..........................71 OS update via storage ......................71 OS update via OTG port ..................... 72 OS update via FOTA ......................72 Factory Data Reset ........................ 74 © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 7 Charging cradle ........................81 Single Slot Cradle (SSC) ....................81 2SC (2 Slot Cradle) ......................81 4SBC (4 Slot Battery Cradle) ....................81 SAFETY INFORMATION ..................82 Battery Safety Information ..................... 82 © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 8: Getting Started

    USB Type C connector for charging and data communication Speaker Ring system sound Use PTT function or scan a barcode by pressing Push-To-Talk / Scan button (Programmable button) Control the volume Volume up & down button (Programmable button) © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 9 Power button Turn on/off the device Take a picture Rear camera & Flashlight & Use flashlight in camera or torch mode Scanner Scan a barcode Hand strap hole (top) Attach hand strap © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 10: Product Standard Accessories

    The following items are in the product box. Accessory Name Battery pack AC/DC Adapter Country plug USB type C cable LCD protection film Hand strap Note: The images may differ from the actual accessory. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 11: Install Sim & Sd Card

    1. Open the battery cover while pressing the battery cover release button. Using the small latch on both sides of the cover, pull it up. Figure 3 Opening battery cover 2. Remove the battery. © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 12 Figure 5 Placing Nano SIM card Figure 6 Placing microSD card 5. Gently insert the card tray. Caution: Do not push the card tray into the device too hard. The card tray may be damaged. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 13: Install & Remove Battery

    Figure 7 Opening battery cover 2. Align the connector (gold contact) of the battery with the battery connector of device. 3. Insert the battery from top to bottom into the slot. Figure 8 Inserting battery © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 14: Remove The Battery

    Figure 10 Removing battery Battery Hot Swap PM75 supports the Battery hot swap mode which allows you to replace the battery without turning off the device. When the battery is removed from the device, the display turns off and the device enters Hot swap mode (For verification, a red LED will be turned on).

  • Page 15: Charge The Device

    PM75 Android 11 User Manual Getting Started Charge the device Before using PM75, charge the device enough to use. PM75 can be charge with power adapter or charging cradle. Battery Specification  Capacity: Standard: 2,900mAh / 3.85V Extended: 5,800mAh / 3.85V ...
  • Page 16 To set smart charging mode, go to Settings > Battery > Smart Charging or EmKit > EmSettings > Smart Charging. Figure 11 Smart charging Find detail information of each mode in Detail and select the desired mode. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 17: Charge With Power Adapter

    PM75 Android 11 User Manual Getting Started Charge with power adapter Caution: Always use an original charger and cable from Point Mobile. Other chargers and cables may damage the device. Also, make sure the charger and cables are not wet. Follow the battery safety information for safety of using the battery.

  • Page 18: Charging Cradle

    1. Assemble the power adapter and AC plug, and connect it to the cradle to provide power. 2. Install PM75 only or PM75 with sled type accessory mounted. Make sure the charging LEDs of the PM75 light up, and a charging icon is displayed on the status bar.
  • Page 19 PM75 Android 11 User Manual Getting Started 2SC (2 Slot Cradle) 2SC has two device charging slots. With 2SC, up to 2 units of PM75 with no accessories attached can be charged simultaneously. To charge the devices via 2SC, 1. Assemble the power adapter and power cable.
  • Page 20 4SBC has four battery charging slots so it can charge up to 4 batteries at the same time. 4SBC is common for PM85 and PM75 batteries. Insert the battery into the slot, and make sure that the LED indicator lights on (can recognize with slot number).

  • Page 21: Led Indicator

    Cannot recognize the battery Alternately blinking red & green Solid red Device entered hot swap mode Blinking blue Notification existing Notification Blue flash Barcode reading success Red flash Barcode reading failed © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 22: Turn On & Off Pm75

    Getting Started Turn on & off PM75 To turn on the device, - Press and hold the power button on the right side of the PM75 until SMART BEYOND RUGGED logo displays on the screen. Figure 17 Power button To turn off the device, - Press and hold the power button when the screen is on, until the power menu is shown.

  • Page 23: Use A Touch Screen

    One-finger press, wait, lift for select action Drag, Swipe, or Fling One-finger press, move, lift for scroll or tilt action Long-press drag One-finger press, wait, move, lift for pick up and move, or select multiple items action © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 24 Vertical or horizontal swipe in a single direction Pinch Open & Close Two-finger press, move outwards and inwards, lift for zoom in / out action Rotate When PM30 is turning sideways, screen orientation is changing © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 25: System Navigation

    Tap to see the recently used app list. Tap to go to home screen. Home button Long-press to launch the Google Assistant. Back button Tap to go back to previous screen. © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 26 Swipe up from the center-bottom of the screen. Back to previous screen Swipe from the left or right edge of the screen. Launch Google Assistant Swipe up from either the left-bottom or right-bottom. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 27: Learning The Basics

    Learning the Basics Setup Wizard When PM75 starts very first time or boot after factory reset, Setup wizard is launched. Following the steps on the screen, set system language, Google account, Wi-Fi connection and copy the data, etc. Some settings can be skipped, but there may be restrictions on the use of system.

  • Page 28: Home Screen

    Long-press to see the application's options Google search Search an item with Google Favorites tray Place the frequently used apps App folder Apps are organized in the folder. Tap to open the App folder © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 29: Status Bar

    Battery is charging Cannot recognize battery Location service turned on Vibrate mode Speakerphone turned on Phone mic is mute Scanner turned on, Scanner turned on but trigger turned off Alarm is set © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 30: Notification Panel

    Notification panel displays a list of all notifications. Tap a notification to respond. To open the Notification panel, drag the Status bar down. To close the panel, swipe it up. Figure 24 Notification panel © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 31: Quick Setting Panel

    Figure 25 Quick setting panel To edit the configuration of Quick settings panel, 1. Tap on the bottom of the panel. 2. By long-press and dragging the icon, customize the configuration of the panel. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 32: Apps & Widget

    To create the app folder, long-press an app icon and drag it to another app icon. Figure 26 Create app folder To change the folder name, tap the Unnamed Folder and input a new name. Figure 27 Change app folder name © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 33 1. Long-press an app icon from the App drawer. Then, drag it slightly until the Home screen is shown. 2. Place the app icon in the Favorites tray. Figure 29 Add an app to Favorites tray © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 34 1. Long-press an app icon from the App drawer. Then, drag it slightly until the Home screen is shown. 2. Place the app icon where you want. (To cancel to place the app, drag it to Cancel area and release.) Figure 30 Place app in Home screen © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 35 4. Place the widget to the Home screen by dragging. Note: To remove an app or a widget from the Home screen, long-press and drag it to Remove area. Figure 32 Remove from Home screen © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 36: Call

    PM75 Android 11 User Manual Learning the Basics Call Note: Calling is only available on LTE SKU (SKU4 ~ 7). To make or receive a phone call, SIM card is required. Insert SIM card to PM75 first regarding Install SIM & SD card.
  • Page 37 Figure 34 Calling screen Icon Function Name Description Mute Mute microphone Keypad Open the keypad Speaker Speakerphone mode Add call Add another call (Enable when receiver answer the phone) © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 38: Answering A Call

    Answering a call Check the caller’s name and number and tap ANSWER button to answer the phone call. Or tap DECLINE button to decline the phone call. Figure 35 Receiving call © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 39: Contacts

    Add a contact via contacts app Navigate to Contacts from App drawer and tap to add a new contact. Figure 36 Add new contact via Contacts Enter the contact details and tap Save. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 40: Contact Detail

    Send a message Make a Make a video voice call call Tap to edit this contact to open advanced options such as delete, share, block, etc. Figure 38 Contact advanced options © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 41: Message

    1. Launch Message from App drawer. 2. Tap Start Chat and type the receiver’s name or phone number. Figure 39 Message list 3. Input a message. 4. Tap icon to send. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 42: Mtp Connection With Pc

    1. Drag down Status bar and tap Android System notification to change USB preference option. Figure 40 USB connection notification 2. Change the option to File Transfer from No data transfer. Figure 41 USB Preferences setting © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 43: Manage The Files

    PM75 Android 11 User Manual Learning the Basics 3. Now PC can recognize the connected device. Find PM75 device from file explorer of the PC. Figure 42 File explorer on PC Manage the Files Figure 43 FileExplorer main screen Description...
  • Page 44 - Compress: Create Zip file with the selected files or folders - Rename: Rename the file or folder - Get info: Display the file information Selected file or folder is highlighted © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 45: Lock The Screen

    - Swipe: Swipe the lock screen to unlock (Default) - Pattern: Draw a pattern to unlock - PIN: Input a PIN to unlock (At least 4 digits) - Password: Input a password to unlock (At least 4 characters) © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 46: Settings

    > Sound and control the Media, Call, Ring, Alarm volume bars. Figure 48 Volume bars Caution: Using high volume levels for long periods may cause ear strain and increase battery consumption. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 47: Adjust Font Size

    If the font size of the screen is too small or too large, adjust the font size. 1. Go to Settings > Display 2. Tap Advanced 3. Tap Font size 4. Referring to the Preview, set the font size Figure 49 Set font size © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 48: Using The Buttons

    The screenshot image will be saved to Pictures > Screenshots folder in the internal storage. Program Buttons All buttons on the PM75 except power button can be optimized as you want. To map the button to other functions from default, 1.
  • Page 49  SCANNER_B: Trigger button on the gun handle. 3. Choose one function you want to remap 4. Tap OK 5. After changing all key mapping, tap Apply to save the changes © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 50: Camera

    PM75 Android 11 User Manual Camera PM75 has rear camera. To use the camera, open App drawer and tap Camera application Figure 52 is a main screen of Camera application, and Figure 53 is a screen that is displayed when you swipe the screen to right.

  • Page 51: Scanner

    PM75 Android 11 User Manual Scanner Scanner is placed on the top of the PM75. Optimize the scanner settings for working environment and improve the efficiency. Figure 54 PM75 scanner location Turn on / off the Scanner The scanner is turned off by default. To turn on the scanner, follow the steps.

  • Page 52: Scansettings

    - Enable or disable the TouchScan, which is a software scanner button. Place a scan icon in any position and tap the icon to read a barcode. Figure 57 ScanSettings - Basic Figure 56 ScanSettings - TouchScan © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 53: Options

    - Tab - LF - Tap & LF Options  Enable / Disable the center window, Aimer, Illumination.  Set Decode mode & Power save mode. Figure 58 ScanSettings - Options © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 54: Notification

    PM75 Android 11 User Manual Scanner Notification Control the beep sound, LED and vibration option. Figure 59 ScanSettings - Notification © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 55: Wedge

    Wedge Set below items in Wedge settings  Barcode ID  Aim ID  Group separator  Prefix  Suffix  Character set  Extended Wedge Figure 60 ScanSettings - Wedge © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 56: Extended Wedge

    Configuration extended wedge. Figure 61 ScanSettings - Extended wedge For example, make a rule that add a string “Point Mobile” at the start of decoded data whenever decoding CODE128. 1. Tap Style (1) and select Condition (2).
  • Page 57 PM75 Android 11 User Manual Scanner 2. Tap Symbologies and select CODE128 among the symbologies. Figure 63 Extended wedge example_2 3. Tap Style (1) and select Actions (2). Figure 64 Extended wedge example_3 © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 58 4. Tap ADD and select Move to start to point the start of the decoded data. Figure 65 Extended wedge example_4 5. Add another action of which action type is Send string. Set value as “Point Mobile”. Figure 66 Extended wedge example_5...
  • Page 59 PM75 Android 11 User Manual Scanner 6. “Point Mobile” string will be added to decoded COD 128 data. Before After © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 60: Symbologies

    Enable or disable the specific symbology or set detail options. By tapping each symbology name to access detail options. Figure 67 ScanSettings - Symbologies About Find the scanner information or restore the scanner settings to default. Figure 68 ScanSettings - About © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 61: Scan A Barcode

    PM75 Android 11 User Manual Scanner Scan a Barcode Point the scanner at the barcode and press a scan button on the PM75. If another button is set as Use the Buttons – Program scan trigger using Program buttons (Refer to buttons), it can trigger the scan action, too.

  • Page 62: Scandemo

    1. Execute EmKit > ScanDemo 2. Scan a barcode by pressing the scan button on the device or tapping Start scan button on the screen. 3. Find scan result Figure 72 ScanDemo © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 63: Wireless

    Note: Mobile network is supported on PM75 LTE SKU (SKU 4 ~ 7) only. Check if your PM75 is LTE SKU. To connect mobile network, SIM card is required. Insert SIM card into PM75 first referring Install SIM & SD card.

  • Page 64: Wi-Fi

    If there is a saved Wi-Fi network, simply turn on the Wi-Fi through the Quick setting panel. The saved network will be connected automatically. Figure 79 Wi-Fi in Quick setting panel © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 65: Bluetooth

    3. Select the device you want to pair among Available devices list. Figure 81 Bluetooth available devices 4. Follow instructions on the screen (Pairing code or pairing confirmation dialog) and tap PAIR. © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 66: Unpair And Disconnect

    To unpair the device, select the name of the device you want to unpair from CURRENTLY CONNECTED list and tap FORGET Or tap DISCONNECT to disconnect only and not unpair. Figure 84 Forget device © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 67: Change The Bluetooth Device Details

    If no devices are listed under the PREVIOUSLY CONNECTED DEVICES, tap See all. Figure 85 Bluetooth device detail - To change the device’s name, tap on the top of the screen - Turn other settings on or off (Available on some devices) © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 68: Nfc

    Quick setting panel. Figure 86 Turn on NFC in Quick setting panel PM75’s NFC antenna is located around the battery cover release button. Bring the NFC tag close to the battery cover release button (Rear-upper side of the device) as below.

  • Page 69: Rfid

    PM75 Android 11 User Manual Wireless RFID Connect PM75 to the compatible RFID reader, RF750 (sold separately). In order to connect the devices, RFID Control application is required. Download RFID Control from Service Portal and install the app on the PM75.

  • Page 70: System Maintenance

     Manufacturer information (Serial number, Part number, etc.)  Device information (Scanner, Camera, Audio, Display, etc.)  Battery information (Battery charging status, etc.)  App version information (Version of EmKit apps) © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 71: Check Device Health

    - Device life time estimation type A - Battery Voltage - Device life time estimation type B - Battery Temperature - System Temperature - Battery Manufacture Date - Battery Serial Number © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 72: Os Update

    System Maintenance OS Update Periodic update improves the performance of the device. Point Mobile provides up-to-date OS version via Service Portal and FOTA. Update the device via storage, OTG port, and FOTA server. Depending on the workspace environment, choose more suitable method.

  • Page 73: Os Update Via Otg Port

    5. Check if the OS image file shows up under AVAILABLE VERSIONS 6. Tap UPDATE to start the update process OS update via FOTA If PM75 can connect to a network, use the FOTA server for the update. 1. Connect the device with a network 2. Go to Settings >...
  • Page 74 Note: Basically, OS update via FOTA works over Wi-Fi or Ethernet only. To enable the OS update over Mobile Network too, uncheck the setting value in FOTA Settings. Downloading over the Mobile network may result in additional charges. Figure 94 FOTA Settings © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 75: Factory Data Reset

    System Maintenance Factory Data Reset When PM75 work abnormal or there is a need to reset the device, follow the steps below to perform a factory data reset. Caution: Factory data reset will erase all personalized settings and data saved in the device, such as Google account, apps, user data, etc.

  • Page 76: Factory Data Reset Via Recovery Mode

    If device works abnormal so does not turn on, try to perform factory data reset through Android recovery mode. 1. Press and hold power button + volume up + scan (Right) buttons simultaneously when PM75 turned off. Figure 96 Recovery mode button combination 2.

  • Page 77: Accessories

    4SBC (4 Slot Battery Cradle) (Common with PM85 battery) Hand Strap The hand strap is enclosed in the PM75 standard package. Attach the strap and you can grab the device more firmly. Figure 97 Hand strap © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 78: Attach Hand Strap

    1. Using a sharp tool, detach the rubbers on the marked location in the figure below. Figure 98 Attach hand strap_1 2. Disassemble the hand strap into three parts. Figure 99 Attach hand strap_2 © 2021 Point Mobile Co., Ltd. All rights reserved...
  • Page 79 Figure 100 Attach hand strap_3 4. Pass the other end through the loop of the rope, and pull it tight. 5. Reassemble the hand strap parts. Figure 101 Hand strap attached © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 80: Gun Handle

    Gun Handle Attach & Use gun handle Attach PM75 to the gun handle from top side, and push the bottom firmly. Figure 102 Attach PM75 to gun handle With gun handle, you can use additional programmable button. The button is used for triggering scanner usually.
  • Page 81 1. Thread the strap through the hole on the bottom side of the retention fixture. Figure 104 Gun handle - Attach hand strap_1 2. Slide the strap through the buckle at the appropriate length. Figure 105 Gun handle - Attach hand strap_2 © 2021 Point Mobile Co., Ltd. All rights reserved...

  • Page 82: Rf750 (Rfid Sled)

    SSC Quick start guide. 2SC (2 Slot Cradle) 2SC has 2 device slots so it can charge up to two units of PM75 simultaneously. And it can charge the PM75 only. And the cradle can be assembled with up to two more 2SC for share cradle. It can become 4SC (Assemble two pieces), and 6SC (Assemble three pieces).

  • Page 83: Safety Information

    Improper battery usage may result in an explosion, fire, or other critical hazards. Battery Usage & Disposal Guidelines 1. Use only Point Mobile approved batteries and charging accessories. Other batteries and charger may damage the device. 2. Do not disassemble or modify the battery. Do not bend, shred, deform the battery.
  • Page 84 Notice: The battery is consumable goods. Point Mobile provides warranty for battery in 6 months after purchase. If you suspect the battery swelling, change the battery and contact Point Mobile to use safely. © 2021 Point Mobile Co., Ltd. All rights reserved...
