Summary of Contents for Point Mobile PM90

  • Page 2 Unauthorized personnel are strictly prohibited from disassembling the phone. Make sure to use only the power adapter (5V 2A Output AC/DC) that came with PM90. In case your phone does not work as expected, you are strongly recommended to restart it by pressing and holding the power button for at least 12 seconds until the startup screen appears.

  • Page 3: Table Of Contents

    Remove the Battery Cover ......6 Insert the Battery ........7 Close the Battery Cover ......7 Insert and Remove the SIM-SAM card .... 8 Install and Remove the microSD card ..... 9 Charge PM90 ........10 Turn On/Off PM90 ........ 11...
  • Page 4 1 Major Parts Display, Touch panel Power button Receiver Earphone cover Front camera Rear camera Buttons Speaker Scan window Battery cover Volume button Battery cover locker Left scan button USB port cover Right scan button Charging cradle connector...

  • Page 5: Accessary

    2 Accessary 5V 2.0A AC/DC Adapter Micro USB C Type Cable AC plug (US/EU/UK) Battery (2900mAh) Battery (5800mAh) LCD protection film Stylus Wrist landyard...

  • Page 6: Setup Pm90

    3 Setup PM90 Remove the Battery Cover 1. Slide the Battery locker. 2. Lift up the Battery Cover. 3. Remove the Battery Cover.

  • Page 7: Insert The Battery

    Insert the Battery Insert “Battery” from top area. Close the Battery Cover Insert “Battery Cover” from top area first and then put in bottom area. Press battery cover with both hand firmly.

  • Page 8: Insert And Remove The Sim-Sam Card

    Insert and Remove the SIM-SAM card You must insert your SIM card to make phone calls. Please power off your phone before inserting or removing the SIM card. 1. Remove the Battery Cover and the Battery. 2. Lift up the SIM rubber. 3.

  • Page 9: Install And Remove The Microsd Card

    Install and Remove the microSD card 1. Remove the Battery Cover and the Battery. 2. Lift up the SIM rubber. 3. Insert the microSD card into the slot (Gold plate should face down). 4. To remove the microSD card, repeat step1 and step2, then remove the card out of the slot.

  • Page 10: Charge Pm90

    2,900mAh 3.85V Backup Battery 5,800mAh 3.85V Charging time About 5 hours Note: Always use an original charger and cable from the Point Mobile. Other chargers and cables may damage PM90. In addition, make sure connector, charger, cables are not wet.

  • Page 11: Turn On/Off Pm90

    Turn On 1. Press and hold down the “Power Key” for a few seconds. 2. When PM90 enter to the boot mode, it will display “SMART BEYOND RUGGED” logo with short vibration. 3. Release the “Power Key” and wait until PM90 finish booting.
  • Page 12 FCC warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 13 si lebrouillage est susceptible d’en compromettre le fonctionnement. This device is restricted to indoor use only within the 5.15 ~ 5.35GHz Band. Cet appareil est restreint a l'utilisation a l'interieur seulement dans la bande 5.15 ~ 5.35GHz. This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment.

This manual is also suitable for:

Pm90w
