1. PAnel & reMote Control deSCriPtion
1. USB: Connector for external USB 2.0 HighSpeed devices or for Wifi Dongle.
1
1. IF IN: Satellite input. Max. 300mA
2. RS-232: RS-232 port
3. IR-SENSOR: External IR sensor for the IR remote control signals.
4. A/V: Audio/video output.
5. HDMI: HDMI output for connecting to a TV.
6. DC IN: 12 VDC connection (power supply).
PAnel & reMote Control deSCriPtion

1.1. front PAnel deSCriPtion

1.2. reAr PAnel deSCriPtion

2 3 4
