User's Manual · MULTILINK R LT

Chapter 1. Installation.

1.1. Safety Rules
Please read the safety rules carefully before installing this equipment.
1.- Respect ventilation slots of this equipment. Avoid covering them with any object.
2.- Keep clean and without obstacles a minimum radius of 40 cm around this equipment.
3.- Do not place any heating source near this equipment.
4.- Do not install this equipment outside its temperature range.
5.- Avoid placements where liquids could be poured in or with important temperature changes.
6.- Never open the device by yourself. Refer servicing to qualified staff only.
7.- Never open the device when it is connected to electrical current.
8.- During connection it is suitable that the equipment is switched off and not connected to electrical current.
9.- Respect electrical security rules during the assembly. Use materials that fulfill laws in force.
10.- Connecting pin (power plug) must be quickly and simply accessible in order to assure a fast disconnection.
11.- To prevent shock hazard, do not touch the power plug with wet hands. Always unplug the receiver before working on
the connections.
12.- Do not put any heavy objects over this equipment; the equipment could be damaged.
1.2. Complete content
- 1 RCA - SCART cable for the receiver indicated as RECEIVER.
- 1 power adapter. Supply necessary power for correct function of the equipment. Use only supplied adapter.
- 1 Receiver (RECEIVER).
- Instructions manual.
- 1 -
MULTILINK R LT Version_en_1.0
FTE maximal
Reserved of technical modifications and/or errors

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MULTILINK R LT and is the answer not in the manual?

Questions and answers

Related Manuals for FTE Maximal MULTILINK R LT

Summary of Contents for FTE Maximal MULTILINK R LT

  • Page 1: Chapter 1. Installation

    User’s Manual · MULTILINK R LT Chapter 1. Installation. 1.1. Safety Rules Please read the safety rules carefully before installing this equipment. 1.- Respect ventilation slots of this equipment. Avoid covering them with any object. 2.- Keep clean and without obstacles a minimum radius of 40 cm around this equipment.
  • Page 2 User’s Manual · MULTILINK R LT 1.3. Description and connections This equipment let you enjoy your audio and video sets in different rooms than real situation. With high quality of transmitted signals (FM modulation) and stereo sound you’ll get high quality signals where you place the receiver. Is possible to buy only the receiver (with UHF modulator or without) to have one emitter with several receivers (in this case the signals of remote control will come from only one receiver).

  • Page 3: Chapter 2. Configuration

    This system let transmit audio and video signals of any domestic device (VCR / DVD / CAMERA / LASER DISC / etc.) without cables neither complicated installations. Follow next steps to make a correct installation of the MULTILINK R LT: 1.- Once unpacked, check that you got all parts mentioned at the beginning of this manual.

  • Page 4: Anomalies And Solutions

    User’s Manual · MULTILINK R LT ANOMALIES AND SOLUTIONS Before to contact the technical service verify that in the following board there is no the solution to your possible problem or failure in the functioning: Anomaly Possible cause Solution There is no video neither audio in the Lack of signal at the output of the Check that it’s ON and correctly...

  • Page 5: Chapter 3. Technical Features

    50 m direct vision Operating Temperature +10 ~ +50 °C Chapter 4. Conformity declaration CONFORMITY DECLARATION “WE , FTE MAXIMAL, DECLARE THAT THE PRODUCTS MULTILINK R LT ARE IN CONFORMITY WITH FOLLOWING DIRECTIVES Low Voltage Directive 2006/95/EC EMC Directive 2004/108/EC”...
