FTE Maximal DVB 310 S User Manual

NOTE: This user's guide is adapted to software version 3.0.33 dated 02/09/2010.
For future software updates, you can download the user's guide from the following website:
http://www.ftemaximal.com/

Chapter 1. Installation.

1.1. Safety Measures
1.- Never place the device next to hot sources.
2.- Never undergo the device to temperatures that exceed its level of operation.
3.- Never expose the device to leakings nor spatterings.
4.- Never place objects that contain liquids over the device.
5.- Respect the ventilation slots of the device, do not cover them with any kind of object.
6.- The space around the device must be free of objects, in a minimum radius of 40cm.
7.- Avoid locations with possibilities of spilling liquids on the inside of the device, and with important changes of
temperature.
8.- Never open the device by yourself due to electric risk. In case of problems, go always to qualified technicians
9.- Never, under no circumstances, open the device when connected to the electrical net..
10.- During the handling it is better to disconnect the device from the electrical net.
11.- Obey the electricity security rules during the assembling. Use materials that obey the current law.
12.- The connecting plug must be accessible in a fast and simple way to have a fast disconnection.
13.- Never touch the plug with wet hands. Also, disconnect always the device before handling the connections.
14.- Never put any heavy object over the device, since it could get damaged.
15.- If the device is going to remain some time without use, it is recommendable to disconnect it from the electrical net.
16.- The repairmen and the maintenance of the device must be done by TV and radio specialised technicians
1.2. Box content
User's Guide
Depending of model selected, the box will has one of these equipments:
DVB 310 S
User's manual · DVB 310 S / DVB 310 S CI
Link – Input Tunner
F male – F male
Link – Output
modulator
F male – F male
- 1 - DVB 310 S / DVB 310 S CI
DC Cable Cable 12 cm PIN to
PIN RJ45 – RJ45
DVB 310 S CI
version_en_1.2 FTE maximal
