The lightning fl ash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert the user
to "dangerous voltage"
and to prevent from a
risk of electric shock.
Please read the manual carefully before installing the receiver.
Caution: Never open the device by yourself. Dangerously high voltages are present inside the unit. Refer
servicing to qualifi ed staff only.
When installing the receiver, always unplug the receiver from the mains voltage.
Unplug the receiver from the mains in case of long periods without operating the receiver (for example,
during holidays!).
To prevent shock hazard, do not touch the power plug with wet hands.
Always unplug the receiver before cleaning it or working on the connections.
Do not install the receiver close to strong heat sources, and ensure a good aeration if you plan to install
the receiver in a small cabinet.
Before you start operating the receiver, make sure that the satellite antenna is properly built up, optimally
connected and aligned.
The correct place to install the receiver is, of course, near your TV set and any other A/V signal sources
(DVD, VCR, CD, game console, etc.).
Choose a stable support, in which you can easily lay the necessary connecting cables without stumbling-
danger.
The receiver should be installed near an easily accessible outlet.
Do not install the receiver in a place where it can be reached by liquid spills.
Do not put any heavy objects as, for example, a TV-device over the receiver; the receiver could be
damaged.
DO NOT INSTALL THE RECEIVER:
- On an unstable surface
- Subject to direct sunlight
- In high humidity environment
- Outside the receiver's temperature range (+5°...+40°C)
If the receiver is subject to severe temperature changes, it can suffer from water condensation inside.
Switch off the receiver in these cases for at least 2 hours before resuming operation.
SAFETY PRECAUTION
Warning:
To reduce the risk of electric shock,
don't open the cabinet. Refer servicing
to qualifi ed personnel only.
PAG. 2
The exclamation point
within
an
equilateral
triangle
is
intended
to alert the user to
important operating and
maintenance (servicing).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAX S93 and is the answer not in the manual?

Questions and answers

Summary of Contents for FTE Maximal MAX S93

  • Page 1 SAFETY PRECAUTION Warning: The lightning fl ash with The exclamation point arrowhead symbol, within To reduce the risk of electric shock, within equilateral don’t open the cabinet. Refer servicing an equilateral triangle, is triangle intended intended to alert the user to qualifi...
  • Page 2 QUICK INSTALLATION GUIDE NOTE: This user’s guide is adapted to software version 1.72B4 dated 24/03/2010. For future software updates, please visit our website. In order to download the complete user’s guide and get more information about receivers, please visit the website http://receivers.ftemaximal.com QUICK INSTALLATION GUIDE FOLLOW NEXT STEPS FOR THE CORRECT INSTALLATION OF THIS RECEIVER.
  • Page 3: L A N G U A G

    QUICK INSTALLATION GUIDE STEP 2: BASIC CONFIGURATION OF THE RECEIVER The receiver includes an installation assistant (Quick Setup) that will help you to setup the different parameters. When the receiver is turned on at fi rst time (using the button at the rear panel of the receiver), the next menu is shown on the TV (IMAGE 1): The receiver is programmed with all the channels of Astra (at...
  • Page 4 QUICK INSTALLATION GUIDE LNB Power : Here you can set the power output to the LNB. If your receiver is connected to the LNB directly then you need to set the LNB Power to “On”. If your receiver is connected to a multi switch (SMATV signal distribution system) then it may be that you don’t need to provide the power to the LNB (IMAGE 2).
  • Page 5 QUICK INSTALLATION GUIDE are listed. You can stop the scan with [Exit] and save the so far found channels (IMAGE 5). Multi search : Entering in this menu, you can make a search in all the satellites of the list confi gured in the “Satellites list” option. The confi...
  • Page 6 QUICK INSTALLATION GUIDE Channel TV Channel List: This option shows the list of TV stored channels. Radio Channel List: This option shows the list of Radio stored channels. Delete All: This option deletes all TV and Radio stored channels. Installation Antenna connexion: It allows choosing the type of installed antenna, between fi...
  • Page 7 QUICK INSTALLATION GUIDE System Confi guration Language: This option allows choosing the language of the menus. TV System: This option allows choosing the video Standard and other parameters of the screen. Local Time Setting: Time setting menu. Timer: It allows activating/deactivating and confi guring timers. Parental Lock: In this option, user can lock the access to the menu and change the password of the receiver.
  • Page 8: Table Of Contents

    INDEX 1. Panel & Remote Control Description 1.1. Front Panel Description……........…………………………11 1.2. Rear Panel Description……........………….…………………..11 1.3. Remote Control Description…..........…………………………..12 2. Basic Operations 2.1. Standby ……………………..........…………………………………...13 2.2. TTX …………..........……………………………………..13 2.3. Mute……………..........………………………………………..13 2.4. Channel Number…………......……………………………………………………13 2.5. Multi-Pictures……......……………………………………………………………14 2.6. PR + / PR -…..........…………………….…………………………..14 2.7.
  • Page 9 INDEX 4. Installation 4.1. Antenna Connection……......……………………..…………………..20 4.2. Satellite List…………......………………………...………………...20 4.3. Antenna Setup..……......……………………..…………………..21 4.4. Single Search………..…......……………………..…………………..21 4.5. Multi Search………......…………...………..…………………….22 4 . 6 . T P L i s t … … … … … ......… … … … … … … … … . . … … … … … … . . . 2 2 5.
  • Page 10: Panel & Remote Control Description

    PANEL & REMOTE CONTROL DESCRIPTION 1. PANEL & REMOTE CONTROL DESCRIPTION 1.1. FRONT PANEL DESCRIPTION 1. IR-SENSOR: Reception sensor for the IR remote control signals. 2. DISPLAY: 4 Digits to display the program numbers. 3. STAND BY LED: Shows the state of the receiver. 4.
  • Page 11: Remote Control Description

    PANEL & REMOTE CONTROL DESCRIPTION 1. POWER: Switches receiver ON or in stand-by-mode. 2. PR+ / PR-: Changes channel up and down. 3. VOL+ / VOL-: Adjusts audio volume up and down. 4. NUMERIC KEYS: For direct typing values and names.
  • Page 12: Basic Operations

    BASIC OPERATIONS 2. BASIC OPERATIONS ? FREQUENTLY ASKED QUESTION Q: The power of my STB is on and it is running in TV mode but the TV screen shows nothing: A: Make sure the TV set has been set to the correct video input (not the TV channels).
  • Page 13: Multi-Pictures

    BASIC OPERATIONS 2.5. MULTI-PICTURES In TV mode, press [ ] button to enter the Multi-Picture mode (OSD 3). 1. In Multi-Picture mode the screen will display 9 channels’ preview window (static), starting from the current channel. Only the marked preview program is continuously playing. 2.
  • Page 14: Epg

    BASIC OPERATIONS 2.13. EPG 1. The STB supports Electronic Program Guides (EPG) to give you information about the actual programs of certain channels like event name, subtitle, description, start and fi nish time. This feature is depending on the service of the channel provider. Press [EPG] to open the EPG window (OSD 5).
  • Page 15: Information

    BASIC OPERATIONS 2.17. INFORMATION In TV mode, press [INFO] button can open information screen (OSD 10), in the window shows the parameters of current channel. 2.18. SAT Press [SAT] button to open the SAT list. After selecting a satellite the channel list will be reduced to the channels of this satellite.
  • Page 16: Channel

    CHANNEL 3. EDIT CHANNEL Press [Menu] in the TV mode to enter the main menu. 1. Press [ ] to select the Edit Channel item. 2. Press [OK] to enter the selected item. OSD 12 3. Enter the password. The default password is “0000”. In the Edit Channel menu (OSD 12): 4.
  • Page 17: Edit Channel

    CHANNEL 3.1.3. EDIT CHANNEL 1. Press [Blue] button to open the “Edit” window. 2. You can Delete, Sort, and Edit the channel (OSD 16). 3. Press [Exit] to leave the Channel Editing. The system will ask you to confi rm the saving of the changes you made. 3.1.3.1.
  • Page 18: Radio Channel List

    CHANNEL 3.2. RADIO CHANNEL LIST Basically the operation of “Radio Channel List” is same as “TV Channel List”, except that in the small channel window a static background will be displayed (OSD 22). 3.3. DELETE ALL A safety question will show up where you have to confi rm fi rst. Select “Yes”...
  • Page 19: Installation

    CHANNEL 4. INSTALLATION Press [Menu] in the TV mode to enter the main menu. 1. Press [ ] to select the Installation item. 2. Press [OK] to enter the selected item. 3. Enter the password. The default password is “0000”. In the Installation menu (OSD 23): OSD 23 4.
  • Page 20: Antenna Setup

    CHANNEL 4.3. ANTENNA SETUP Depending on how the “Antenna Connexion” section is confi gured, it will allow confi guring different parameters: (Fixed Antenna) • (OSD 27): - Satellite: Press [ ] to switch Satellites or press [OK] to enter satellite list to select directly. - LNB frequency: Use [ ] in order to change among “Universal”, a specifi...
  • Page 21: Multi Search

    INSTALLATION free channels or even scrambled channels. If you select “Yes” it will scan free channels only. 3. In “Scan Channel” item, press [ ] to select to scan TV + Radio Channels, just TV channels or just Radio channels. 4.
  • Page 22 INSTALLATION you can edit the Transponder’s data like frequency, polarity and Symbol Rate. In this window, the search of the channels of the TP can be done selecting the “Search” option and pressing [OK]. 3. Press [Green] button to open the “Add TP” menu (OSD 35).
  • Page 23: System Setup

    INSTALLATION 5. SYSTEM SETUP Press [Menu] in the TV mode to enter the main menu. 1. Press [ ] to select the System Setup item. 2. Press [OK] to enter the selected item. In the System Setup menu (OSD 38): 3.
  • Page 24: T V S Y S T E

    INSTALLATION Italian, Portuguese, Turkish, Polish, Russian, Arabic, Farsi. 6. Press [Exit] to return back from “Language” menu. 5.2. TV SYSTEM When you enter the “TV System” menu you will see the screen like below (OSD 40): 1. Display Mode is used to switch the display mode. You can select from Auto / PAL / PAL-M / PAL-N / NTSC.
  • Page 25: Parental Lock

    INSTALLATION 3. Wakeup Date: use number keys to input your wakeup date. 4. On Time: use number keys to input your wakeup time. Once the time’s up, no matter what the system is in standby mode or in playing mode, the system will automatically switch to the channel you want and start to play.
  • Page 26: Favorite

    SYSTEM SETUP 2. OSD Timeout: This setting determines the duration the info window is displayed on the screen when you change channels. Press [ ] to set the time between 1 to 10 seconds. 3. OSD Transparency: With this parameter you can set the transparency of the menus.
  • Page 27: Beeper

    SYSTEM SETUP ] in order to select between “Black screen” or “Freeze” (it will show the frozen image of the cannel you were watching). 5.8.4. BEEPER If you select “Beeper” option as “On”, when you are tuning channels, the receiver will announce a tone according to the level of power of the received signal.
  • Page 28: Tools

    TOOLS 6. TOOLS Press [Menu] in the TV mode to enter the main menu. 1. Press [ ] to select the Tools item. 2. Press [OK] to enter the selected item. 3. Enter the password. The default password is “0000”. OSD 49 In the Tools menu (OSD 49): 3.
  • Page 29: Software Upgrade By Ota

    TOOLS 6.4. UPGRADE BY SATELLITE This function can upgrade the software of your receiver through data sent by a satellite. At the moment we offer satellite updates only through ASTRA1 satellite. 1. Select the satellite and TP or input the TP value and download PID.
  • Page 30: Tetris

    TOOLS 7. TOOLS Press [Menu] in the TV mode to enter the main menu. 1. Press [ ] to select the Game item. 2. Press [OK] to enter the selected item. OSD 55 In the Games menu (OSD 55): 3. Press [ ] to select the wanted menu item.
  • Page 31: Technical Specification

    TECHNICAL SPECIFICATION 8. TECHNICAL SPECIFICATION VIDEO Decoding MPEG-2 & MEPG-1 compatible Bit rate Max 15Mbps Output PAL/NTSC Active pixel 720x480 @ 30fps; 720x576 @25fps Output connector Scart AUDIO Decoding MPEG-2/MPEG-1 layer I & II Mode Mono, Dual, Stereo, Joint stereo Bit rate Max 384Kbps Output connector...
  • Page 32: Conformity Declaration

    CONFORMITY DECLARATION “WE , FTE MAXIMAL, DECLARE THAT THE PRODUCTS MAX S93 IS IN CONFORMITY WITH FOLLOWING DIRECTIVES LOW VOLTAGE DIRECTIVE 2006/95/EC EMC DIRECTIVE 2004/108/EC” PAG. 33...
