Connections and controls
Forward button. Press the button briefly to skip to the next track. Keep this button pressed to search forward for a
specific part of the current track.
6 [MASTER]
Rotary control to adjust the overall volume
7 [MUSIC] / [SPEECH] — [BASS BOOST]
Rotary control to adjust the bass.
Turn the control to the left to reduce the bass. Turn the control to the right to increase the bass.
8 [LEVEL]
Rotary control for adjusting the volume of the input signal at the line input
9 [STANDBY DISABLE | ENABLE]
When the switch is in the position [ENABLE], the device will turn off after approx. 30 minutes without input signal. To
turn it then back on again, switch [POWER] off and on again.
The indicator LED lights green during normal operation. If there is no signal input at the [MIC/GUITAR] jack for 30
minutes and the standby function is activated, the device will enter standby mode and the indicator LED lights red.
