thomann FunGeneration Speaker ToGo BT User Manual

thomann FunGeneration Speaker ToGo BT User Manual

Mobile pa system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Speaker ToGo BT
mobile PA system
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FunGeneration Speaker ToGo BT and is the answer not in the manual?

Questions and answers

Related Manuals for thomann FunGeneration Speaker ToGo BT

Summary of Contents for thomann FunGeneration Speaker ToGo BT

  • Page 1 Speaker ToGo BT mobile PA system user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 22.06.2016, ID: 378744 (V2)

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................4 1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 6 Safety instructions............................. 8 Features............................... 12 Installation and starting up........................ 13 4.1 Battery operation..........................14 4.2 Set-up..............................14 Connections and controls........................

  • Page 4: General Information

    General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual.

  • Page 5: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 6: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual.
  • Page 7 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in minor injury if it is not avoided.

  • Page 8: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used in a sound reinforcement system. Use the device only as described in this user manual. Any other use or use under other operating conditions is consid‐ ered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
  • Page 9 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug.
  • Page 10 Safety instructions CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment.
  • Page 11 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.

  • Page 12: Features

    Features Features The mobile PA system is characterized by the following features: Compact all-in-one system Maximum flexibility thanks to mains and battery operation 10" woofer and tweeter Output power 50 W (peak) Frequency response 70 Hz … 20 kHz ± 3 dB 3-band EQ Bluetooth®...

  • Page 13: Installation And Starting Up

    Installation and starting up Installation and starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.

  • Page 14: Battery Operation

    Installation and starting up 4.1 Battery operation You can also operate the device independently of mains power supply via the built-in rechargeable battery. 4.2 Set-up You can operate the device standing on the floor or on a suitable speaker stand using the tripod flange at the bottom.

  • Page 15: Connections And Controls

    Connections and controls Connections and controls Front panel Speaker ToGo BT...
  • Page 16 Connections and controls 1 [CH 1] Balanced XLR / 1/4" combo input for channel 1 to connect microphones that don't need phantom power. 2 [LEVEL] Volume control for channel 1. Turn the control to the right to increase the volume. in this channel. Turn it to the left to reduce the volume.
  • Page 17 Connections and controls 6 [LEVEL] Volume control for channel 3. Turn the control to the right to increase the volume. in this channel. Turn it to the left to reduce the volume. 7 [PAIRED / DISCONNECTED] Push button to enable / disable the Bluetooth® function with indicator. A few seconds after switching the function on, the indicator in the push button lights up red and an acoustic signal sounds.
  • Page 18 Connections and controls 9 [MIDDLE] Mids control. Turn the control to the right to increase the mids. Turn it to the left to reduce the mids. When it's in the lock-in position ‘0’ the signal remains unaffected. 10 [BASS] Bass control. Turn the control to the right to increase the bass. Turn it to the left to reduce the bass. When it's in the lock-in position ‘0’...
  • Page 19 Connections and controls Rear panel Speaker ToGo BT...
  • Page 20 Connections and controls 13 [POWER INPUT] Plug for mains cable with fuse holder. To operate the device via the power grid, connect this plug using the supplied power cord to an AC outlet. 14 [CHARGE] If the charge indicator light is on, the internal battery is being charged. After the LED goes out, the battery is fully charged.
  • Page 21 Connections and controls 17 [LINK OUTPUT] The line level output signal of the device to connect amplifiers, active monitors or recording devices is present at this 1/4" socket. The signal is subject to EQ but is not affected by [MASTER VOL] to set the overall volume. 18 [SOUND SYSTEM BATTERY LEVEL] Charge indicator for the built-in battery.

  • Page 22: Technical Specifications

    Technical specifications Technical specifications Amplifier / speaker Inputs 1 × XLR/6.35 mm combo jack as microphone input 1 × 6.35 mm jack as microphone / instrument input 1 × 3.5 mm jack as line input 1 × Bluetooth® interface for wireless audio transmission Outputs 1 ×...
  • Page 23 Technical specifications General Voltage supply 230 V , 50 Hz 12 V lead gel battery (10 Ah), maintenance-free Fuse 5 mm × 20 mm, 800 mA, 250 V, slow blow Operating time after a battery charging approx. 20 h Dimensions (W × H × D) 437 mm ×340 mm ×507 mm (15.35in.

  • Page 24: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 25 Plug and connection assignment Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter‐ ference. 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4"...
  • Page 26 Plug and connection assignment Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) mobile PA system...

  • Page 27: Cleaning

    Cleaning Cleaning Device components Clean the device components that are accessible from the outside regularly. The cleaning fre‐ quency depends on the operating environment: damp, smoky or particularly dirty environ‐ ments can cause greater accumulation of dirt on the device components. Clean with a dry soft cloth.

  • Page 28: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 29 Notes Speaker ToGo BT...
  • Page 30 Notes mobile PA system...
  • Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
