Configure a streaming destination
1. Go to Extra > Streaming.
2. Go to Destination.
3. In Mode, select Client mode.
4. Toggle Remember Key to save the destination streaming keys in the device memory.
5. Go to Destination Settings.
a. Select a Destination slot.
b. Enter a Label.
c. Enter an RTMP or RTMPS URL.
d. If needed, enter a Streaming Key.
e. If needed, select Reset.
Streaming in Client mode
1. Go to Extra > Streaming.
2. Go to Destination.
3. In Mode, select Client mode.
4. Select a destination to use.
5. Go to Video,
a. In Source, select the Input, Output or Multiviewer source to stream.
b. In Quality, select Low, Medium or High.
Or select Custom Bitrate and enter a value in kbps.
6. Go to Audio > Mode, select to Follow content or select Direct routing and set the audio source.
7. Go to Control to check the stream status.
8. Press Enter to start (or stop) the stream.
The stream starts and the Stream settings cannot be applied until the stream stops.
9. If needed, in Audio, mute the stream or change the pair of audio channels to use.

Services

Export device configuration to a USB drive
1. Connect a USB drive on the front panel USB plug.
2. Go to Services > Device Config > Export.
3. Select the settings to export (All is selected by default).
4. Go to Select Path.
5. Browse the USB drive folders and select EXPORT TO THIS FOLDER.
Import device configuration
1. Connect a USB drive on the front panel USB plug.
2. Go to Services > Device Config > Import.
3. Browse the USB drive folders and select the configuration file to import.
