INSTRUCTION MANUAL
713
Plumbers Stud Punch
Read and understand all of the instructions and
Safety information in this manual before operating
or servicing this tool.
© 2019 Greenlee Tools, Inc.
IM 1542 REV 2 1019
999 4220.8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Greenlee 713
Summary of Contents for Greenlee 713
- Page 1 INSTRUCTION MANUAL Plumbers Stud Punch Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. © 2019 Greenlee Tools, Inc. IM 1542 REV 2 1019 999 4220.8...
- Page 2 Hazards or unsafe practices which, if not avoided, MAY result in injury or property damage. • Inspect the tool prior to use. Replace worn, damaged, or missing components with Greenlee replacement parts. A damaged or improperly assembled tool can break.
- Page 3 20 gauge steel studs. handle forward, using the slot to extend the handle. The 713 punches a 66.9 mm (2-5/8") diameter hole to 2. Spread the handles apart to lift the punch and clear accommodate a 2" inside diameter PVC white or CPVC the opening in the C-head.
- Page 4 713 Plumbers Stud Punch Exploded View and Parts List GREENLEE UPC NO. PART 78-3310- DESCRIPTION QTY. 50617 905 0617.0 Screw, 1/4–20 UNC set ......1 10465 501 0465.9 C-head unit (includes one of item 14) ..1 08379 500 8379.1 Die .............
