QUICK START PROCEDURE
Setup Procedure without the DC590
1. On the DC1366B:
a. Set JP5 to EXT V
b. Set JP4 (AUTO) to the HI position.
c. If midspan operation is desired set JP2 to HI, for
endpoint set to LO.
2. Connect a 3.3V power supply across +3.3V and DGND
test points as shown in Figure 1. Turn on the 3.3V
supply and verify the V
3. Before connecting the main power supply to the
DC1366B verify the voltage is between 51V and 57V,
and that the main supply is turned off.
Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from
.
DD
LED on the DC1366B is lit.
DD
DEMO MANUAL DC1366B
4. Connect the main power supply to the DC1366B with
two banana patch cords as shown in Figure 1. Verify
the polarity is correct before turning on the power;
positive goes to RTN and negative to V
5. Turn on the main power supply and verify the V
on the DC1366B is lit.
6. Connect PDs to any of the ports on the OUT TO PD
side of the DC1366B and verify they turn on by the
respective OUTn LED.
.
EE
LED
EE
