TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
SECTION « A » DESCRIPTION
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Distances to respect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation / instruction for oven and proofer. . . . . . . . . . . . . . . . . . . . . . . . A6
Operation for proofer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oven maintenance and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For more information, please contact our office: . . . . . . . . . . . . . . . . . . . .
Optional auto steam injection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Optional watlow control operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JA10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JAOP10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JA20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION « E » COMPONENT PARTS
Component parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION « F » CONTROL PANELS
JAOP10 120V/208V/1PH & 120V/240V/1PH . . . . . . . . . . . . . . . . . . . .
JAOP10 120V/208V/3PH & 120V/240V/3PH . . . . . . . . . . . . . . . . . . . .
JAOP10 220V/1PH/50 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JA10 208V/3PH & 220V/3PH & 240V/3PH . . . . . . . . . . . . . . . . . . . . . . F7
JA20 120V/208V/1PH & 120V/240V/1PH . . . . . . . . . . . . . . . . . . . . . . . F9
JA20 120V/208V/3PH & 120V/240V/3PH . . . . . . . . . . . . . . . . . . . . . . . F11
JA10, JAOP10 & JA20
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
CAREFULLY FOLLOW THESE INSTRUCTIONS

TABLE OF CONTENTS

DANGER
PAGE
A3
A4
A8
E1
F1
F3
F5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JA10 and is the answer not in the manual?

Questions and answers

Related Manuals for Doyon JA10

Summary of Contents for Doyon JA10

  • Page 1: Table Of Contents

    Troubleshooting ..........Oven maintenance and cleaning ....... . .
  • Page 2 SECTION « G » ELECTRIC SCHEMATICS JA10 120V/208V/1PH & 120V/240V/1PH ..... JA10 120V/208V/3PH & 120V/240V/3PH .....

  • Page 3: Introduction

    This Jet Air oven is manufactured with first quality material by experienced technicians. Proper installation and maintenance will guarantee a reliable service for years to come. A nameplate fixed to the front or right side of the oven specifies the model number, serial number, voltage and amperage.

  • Page 4: Construction

    CONSTRUCTION You just bought the most advanced oven in the world, "DOYON" technology at its best. This oven is manufactured using the highest quality components and material. The oven gives a perfect uniform baking with its unique Jet Air convection system. The DOYON oven is designed with parts that are easy to find.

  • Page 5: Installation Warnings

    Installation and service must be done by specialised technicians. Contact a certified electrician and plumber for set up. The oven must be connected to the utility and electrically grounded in conformity to the effective local regulations. If these are not established, the oven must be connected according to the Canadian Electrical Code (CSA-C22.1-XX) or National Electrical Code (NFPA 70-XX).

  • Page 6: Distances To Respect

    DISTANCES TO RESPECT Back and sides of the oven: 1 inch. Top of the oven: a clearance of 12 inches to the ceiling must exist to permit adequate venting. Floor: 4 inches minimum. Sides of the oven: do not install other than easily removable equipment for service and maintenance (not closer than 1 inch).

  • Page 7: Installation

    Connect the steam system (1/4 NPT) to the cold water distribution network. We highly recommend to use a water softener to eliminate minerals in the water. We suggest you to use CUNO # CFS6135 (Doyon part number PLF240). Do not adjust the needle valves, it has been done at the factory.

  • Page 8: Troubleshooting

    5. Set the timer to the desired value and start it. (See "TIMER" adjustment on next page.) NOTE: The timer does not shut the oven off at the end of its cycle. It simply activates the buzzer. 6. Wait until the product is ready. Do not open the doors until the product is done.

  • Page 9: Instructions For Oven

    Steam injection will only work when the ventilator of the oven is working. To inject steam in the oven, press and release the STEAM TIMER button. The light comes on inside the steam button during the steam injection. Steam injection has been factory preset. To have more steam, press steam button a second time, after the light is off.

  • Page 10: Operation Of The Proofer

    OPERATION OF THE PROOFER 1. Switch "ON". 2. Set the thermostat control at 100 3. Set the humidity control at approximately : 3 for JAOP-3 & JAOP-6 4. If there is too much fog and water drips from the glass doors, adjust humidity control to a lower number.

  • Page 11: Troubleshooting

    If the oven is baking too much on the sides, it is possible that the fan is not cycling properly. Verify if the motor turns 2.5 minutes in a direction, stops 30 seconds and starts for 2.5...
  • Page 12 If there is no heat in the proofer. If there is no humidity in the proofer. The oven must have been heating for at least half an hour before you use the steam system. If not, water will appear at the bottom of the oven.

  • Page 13: Oven Maintenance And Cleaning

    • Once a year or as needed, clean the reservoir of the proofer (see parts description for localization). Step by step Clean the inside of the oven and the proofer with water and soap. Take out the grills (the grills of the oven could be cleaned with "Easy-Off").

  • Page 14: For More Information, Please Contact Our Office

    FOR MORE INFORMATION, PLEASE CONTACT OUR OFFICE: DOYON EQUIPMENT INC. 1255, rue Principale Linière, Qc, Canada G0M 1J0 Tel. : 1 (418) 685-3431 Canada : 1 (800) 463-1636 U.S. : 1 (800) 463-4273 FAX : 1 (418) 685-3948 Internet: http://www.doyon.qc.ca E-Mail : doyon@doyon.qc.ca...

  • Page 15: A13

    AUTOMATIC STEAM OPTION INTERVALS TIMES SETTING (GREEN) INJECTION TIMES SETTING (RED) SCALE ADJUSTMENT By pushing the GREEN button, the button will light up and the automatic system injection will start. The injection will be done as per the pre-adjustment time on the automatic steam timer. The standard steam timer (white light) will light up during the steam injection.

  • Page 16: A14

    Digital display must light up, if not verify the breaker on the front panel. 3. Let the oven heat until the set temperature is reached, the LOAD1 red light on the watlow control will go off when the temperature is stabilized.
  • Page 17 The Watlow temperature control can record 12 different menus. It must be programmed before use. It will save its programs in case of power failure. Each menu includes 3 "STEPS" and each step includes : • temperature • time • "EVENT" To access the programming mode : •...
  • Page 18 CLOCK). The screen will show 00:00. Note: You should always use menu #1 for preheating because the controls starts automatically with this menu. Never use program #1 for a steam cycle because it will start automatically when the oven is Suggested values Suggested values WARNING turned on.
  • Page 19 EXAMPLE 2 (Cooking program with steam cycle) -For menu #2, we will program it so that we have a steam injection of 20 seconds, a cooking time of 20 minutes at 375°F followed by a 15 seconds buzzer. To access the programming mode: •...
  • Page 20 After fulfillment of this program: • The oven will continue to heat because there was a temperature included in step 3. If the temperature at that step would have been of 0°F, the oven would have stopped at the end of the program.

  • Page 21: Section « B » Dimensions

    SECTION DIMENSIONS...

  • Page 22: Ja10

    JA10 53 1/2 SLIDING DOORS OVEN INTERIOR DIMENSIONS HEIGHT 26 1/2" WIDTH 39" DEPTH 30 3/4" JA10 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR...
  • Page 23 JA10PEN 53 1/2 DOORS WITH HIGES OVEN INTERIOR DIMENSIONS HEIGHT 26 1/2" 39" WIDTH DEPTH 30 3/4" JA10 TIMER OMRON H5CL START/STOP DEPART/ARRET 34 1/2 STEAM TIMER MINUTERIE VAPEUR...
  • Page 24 JA10 50 1/2 SLIDING DOORS JA10...
  • Page 25 JA10 ENTRÉE D’EAU Ø1/4" WATER INLET Ø1/4" ENTRÉE ÉLECTRIQUE ELECTRICAL INLET JA10...

  • Page 26: Jaop10

    INTERIOR DIMENSIONS HEIGHT WIDTH DEPTH JAOP10 53 1/2 SLIDING DOORS OVEN PROOFER INTERIOR DIMENSIONS 26 1/2" HEIGHT 39" WIDTH 30 3/4" DEPTH JAOP10 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR 73 1/4 THERMOSTAT OFF / ON ARRET/DEPART 20 AMPS 20 AMPS 27"...
  • Page 27 INTERIOR DIMENSIONS HEIGHT WIDTH DEPTH JAOP10PE 53 1/2 DOORS WITH HIGES OVEN PROOFER INTERIOR DIMENSIONS 26 1/2" HEIGHT 39" WIDTH 30 3/4" DEPTH JAOP10 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR 72 3/4 THERMOSTAT OFF / ON ARRET/DEPART...
  • Page 28 JAOP10 50 1/2 73 1/4 SLIDING DOORS JAOP10...
  • Page 29 JAOP10 ENTRÉE D’EAU Ø1/4" WATER INLET Ø1/4" ENTRÉE ÉLECTRIQUE ELECTRICAL INLET JAOP10...

  • Page 30: Ja20

    JA20 53 1/2 SLIDING DOORS OVEN INTERIOR DIMENSIONS HEIGHT 26 1/2" WIDTH 39" 30 3/4" DEPTH JA20 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR 73 1/4 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR ARRET/MARCHE 5 AMPS...
  • Page 31 JA20PEN 53 1/2 DOORS WITH HIGES OVEN INTERIOR DIMENSIONS HEIGHT 26 1/2" WIDTH 39" DEPTH 30 3/4" JA20 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR 72 3/4 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR ARRET/MARCHE 5 AMPS...
  • Page 32 JA20 51 1/2 73 1/4 SLIDING DOORS JA20...
  • Page 33 JA20 ENTRÉE D’EAU Ø1/4" WATER INLET Ø1/4" ENTRÉE ÉLECTRIQUE ELECTRICAL INLET JA20...

  • Page 34: Component Parts

    SECTION COMPONENT PARTS...
  • Page 35 JAOP10 SLIDING DOORS JAOP10 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR THERMOSTAT OFF / ON ARRET/DEPART 20 AMPS 20 AMPS...
  • Page 36 JAOP10PE DOORS WITH HIGES JAOP10 TIMER OMRON H5CL START/STOP DEPART/ARRET STEAM TIMER MINUTERIE VAPEUR THERMOSTAT OFF / ON ARRET/DEPART 20 AMPS 20 AMPS...
  • Page 37 QUA200 DOOR MAGNET P2027FG LEFT SLIDING DOOR FOR OVEN QUE100 FIBERGLASS DOOR GASKET(5`) STS200 DOOR SEAL FOR JAOP-10 P2028FG LEFT DOOR WITH HINGES FOR OVEN QUE500 DOOR GASKET(16`) STP001 TOP MALE HINGE STP002 TOP FEMALE HINGE STP003 BOTTOM MALE HINGE...
  • Page 38 ELI240 INFINITY SWITCH KNOB ELB097 20A BREAKER Model : JAOP10-E View : FRONT...
  • Page 39 JAOP10W SLIDING DOORS JAOP10 WATLOW ARRET/MARCHE OVERHEAT WARNING AVIS DE SURCHAUFFE THERMOSTAT OFF / ON ARRET/DEPART 20 AMPS 20 AMPS...
  • Page 40 DOOR GASKET(5`) AND STS200 DOOR SEAL FOR JAOP-10 P2027ED RIGHT SLIDING DOOR FOR PROOFER QUA200 DOOR MAGNET P2027FG LEFT SLIDING DOOR FOR OVEN AND QUE100 FIBERGLASS DOOR GASKET(5`) AND STS200 DOOR SEAL FOR JAOP-10 P2027FD RIGHT SLIDING DOOR FOR OVEN ELM570...
  • Page 41 JAOP10 SLIDING DOORS JAOP10...
  • Page 42 JAOP10PE SLIDING DOORS JAOP10...
  • Page 43 Item Part Number Description ELE165 IMMERSION ELEMENT 120V 1500W ELE167 IMMERSION ELEMENT 240V 1500W(50Hz) ELE130 COIL ELEMENT 120V 1500W ELE132 COIL ELEMENT 240V 1500W(50Hz) ELM730 PROOFER FAN BLOWER ELM570 DOOR SWITCH ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V ELA290 BULB 60W, 240 V(50Hz) ELS950 BUZZER 120V...
  • Page 44 JAOP10W SLIDING DOORS JAOP10 WATLOW...
  • Page 45 Item Part Number Description ELE165 IMMERSION ELEMENT 120V 1500W ELE167 IMMERSION ELEMENT 240V 1500W(50Hz) ELE130 COIL ELEMENT 120V 1500W ELE132 COIL ELEMENT 240V 1500W(50Hz) ELM730 PROOFER FAN BLOWER ELS950 BUZZER 120V ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V ELA290 BULB 60W, 240 V(50Hz) ELT503 HIGH LIMIT SWITCH 140°F...

  • Page 46: Control Panels

    SECTION CONTROL PANELS...
  • Page 47 240 VOLTS 1 PHASE SIMPLE − DELAY PAN240S...
  • Page 48 ELM720 OMRON CONTROL TIMER (11 PIN) H3CR(DELAY OPTION) AND ELM729 11 PIN BASE(DELAY OPTION) ELC630 CONTROL RELAY 12A COIL 120V(AUTO. STEAM OPTION) AND ELC640 CONTROL RELAY BASE(AUTO. STEAM OPTION) Model : PA240SP(JAOP6) Description View : INSIDE (See OVEN BACK) Quantity...
  • Page 49 208 VOLTS 3 PHASES SIMPLE−DELAY PAN208S...
  • Page 50 OMRON STEAM TIMER H3DE ELM720 OMRON CONTROL TIMER (11 PIN) H3CR(DELAY OPTION) ELM729 11 PIN BASE(DELAY OPTION) ELC630 CONTROL RELAY 12A COIL 120V(AUTO. STEAM OPTION) ELC640 CONTROL RELAY BASE(AUTO. STEAM OPTION) Model : PA208S(JAOP6) Quantity View : INSIDE (See OVEN BACK)
  • Page 51 220 VOLTS 1 PHASE SIMPLE − DELAY PAN220S...
  • Page 52 ELM720 OMRON CONTROL TIMER (11 PIN) H3CR(DELAY OPTION) AND ELM729 11 PIN BASE(DELAY OPTION) ELC630 CONTROL RELAY 12A COIL 120V(AUTO. STEAM OPTION) AND ELC640 CONTROL RELAY BASE(AUTO. STEAM OPTION) Model : PA220SP Description View : INSIDE (See OVEN BACK) Quantity...
  • Page 53 220 VOLTS 3 PHASES SIMPLE X3 X1 H2 H4 PAN220−3...
  • Page 54 MOTOR REVERSING CONTACTOR 2HP ELC505B CONTACTOR COIL (ONLY) ELB073 TERMINAL BLOCK 30A ELM715 PRESET TIMER 25SEC. OFF - 150SEC. ON ELL050 GROUND LUG ELF995 FUSEHOLDER 30A 250V 3P ELF820 FUSE 8A 250V Model : PAN220-3 Description View : INSIDE (See OVEN BACK) Quantity...
  • Page 55 208 OR 240 VOLTS 1 PHASE DOUBLE PAN240D...
  • Page 56 CONTROL RELAY 12A COIL 120V(3 FOR AUTOM. STEAM) AND ELC640 CONTROL RELAY BASE(3 FOR AUTOM. STEAM) ELB073 TERMINAL BLOCK 30A ELF970 FUSE HOLDER 30A 250V 2P ELF840 FUSE 20A 250V ELM614 OMRON STEAM TIMER H3DE Model : PA240D Description View : INSIDE (See OVEN BACK) Quantity...
  • Page 57 208 OR 240 VOLTS 3 PHASES DOUBLE PAN208D...
  • Page 58 ELO098 OVERLOAD TELEMECANIQUE 2.5 TO 4 AMPS ELO098 OVERLOAD 2.5 - 4 Amps. ELF830 FUSE 15A 250V ELF995 FUSEHOLDER 30A 250V 3P ELM614 OMRON STEAM TIMER H3DE Model : 208V 3PH DOUBLE Description View : INSIDE (See OVEN BACK) Quantity...
  • Page 59 240 VOLTS 1 PHASE SIMPLE PAN240WA...
  • Page 60 CONTROL RELAY BASE ELB073 TERMINAL BLOCK 30A ELF970 FUSE HOLDER 30A 250V 2P ELF820 FUSE 8A 250V ELS950 BUZZER 120V ELM735 SOLID STATE TIMER ICM FOR CH460,JAOP3-G, FC2-G AND E233 Model : PAN240WA Description View : INSIDE (See OVEN BACK) Quantity...
  • Page 61 208 VOLTS 3 PHASES SIMPLE PAN208WA...
  • Page 62 CONTROL RELAY 12A COIL 120V AND ELC640 CONTROL RELAY BASE ELF995 FUSEHOLDER 30A 250V 3P ELF820 FUSE 8A 250V ELS950 BUZZER 120V ELM735 SOLID STATE TIMER ICM FOR CH460,JAOP3-G, FC2-G AND E233 Model : PAN208WA Description View : INSIDE (See OVEN BACK) Quantity...

  • Page 63: Electric Schematics

    SECTION ELECTRIC SCHEMATICS...
  • Page 64 120 / 240 TOTAL POWER: 13.5 Kw 60 Hz 3/4HP MOTOR HIGH LIMIT STEAM STEAM TIMER H3DE SWITCH OVEN VALVE MODE E 4.5A 65.0A 60.5A 4.5A 58.0A 53.5A JA10 1 PHASE 60 Hz 25/08/04 M. FAUCHER STANDARD JA10_1 1 / 1...
  • Page 65 BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). HIGH LIMIT STEAM STEAM TIMER H3DE SWITCH OVEN VALVE MODE E 3.3A 36.4A 33.1A 43.0A 4.0A 34.0A 31.0A 40.0A WARNING JA10 3 PHASES 60 Hz 25/08/04 M. FAUCHER STANDARD JA10_3 1 / 1...
  • Page 66 OVEN 5 A. SWITCH HIGH LIMIT 110°F COOLING P.L. PROOFER BULB SWITCH 20 A. 20 A. LIQUID LEVEL PROOFER VALVE ELECTRONIC COM1 TIMER HIGH LIMIT 140°F COOKING TIMER H5CX (MODE A−1) INFINIT SWITCH BULB 2.5KW EACH ELEMENT 3/4 HP MOTOR...
  • Page 67 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). HIGH LIMIT...
  • Page 68 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). ON / OFF / DELAY SELECTOR SWITCH SW 2.3...
  • Page 69 EACH ELEMENT 3/4HP MOTOR TOTAL POWER: 17.8 Kw 50 Hz HIGH THERMOSTAT LIMIT COOKING TIMER STEAM STEAM TIMER H3DE SWITCH OVEN VALVE COOKING SWITCH MODE E PILOT 1.5KW − 240V LIGHT 1.26KW − 220V HUMIDITY PILOT 1.5KW − 240V 1.26KW − 220V...
  • Page 70 SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 220 / 380 8.2A 22.5A 32.0A 26.2A TOTAL POWER: 17.8 Kw 50 Hz...
  • Page 71 120 / 208 130A 123A 120 / 240 115A 107A TOTAL POWER: 27 Kw 60 Hz OL1−95 HIGH LIMIT 500°F STEAM TIMER H3DE OVEN VALVE MODE E OL2−95 STEAM TIMER H3DE OVEN VALVE MODE E JA20 1 PHASE 60 Hz 25/08/04 M.
  • Page 72 DELTA SECONDARY TRANSFORMER, MAKE 3/4 HP MOTOR SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). OL1−95 OL2−95 120 / 208 6.5A...
  • Page 73 100VA OVEN 5 A. 5 A. SWITCH 120−240V> SW 1.1 120−240V BULB HIGH LIMIT 110°F OVEN 100VA 5 A. 5 A. SWITCH 120−240V> SW 2.1 120−240V BULB L1 T1 L2 T2 L3 T3 SW 1.2 OL1−95 COOLING FAN R1−5 HIGH...
  • Page 74 OVEN 5 A. SWITCH HIGH LIMIT 140° HIGH LIMIT 110° COOLING BULB P.L. PROOFER SWITCH 20 A. 20 A. LIQUID LEVEL BULB PROOFER VALVE L1 T1 L2 T2 ELECTRONIC TIMER R2−4 DOOR DOOR SWITCH SWITCH 120/24V TEMPERATURE & TIMER PROGRAMABLE CONTROL EVENT T°...
  • Page 75 OVEN 5 A. SWITCH HIGH LIMIT 140° HIGH LIMIT 110° COOLING BULB P.L. PROOFER SWITCH 20 A. 20 A. LIQUID LEVEL BULB PROOFER VALVE L1 T1 L2 T2 ELECTRONIC TIMER R2−4 DOOR DOOR SWITCH SWITCH 120/24V TEMPERATURE & TIMER PROGRAMABLE CONTROL EVENT T°...

  • Page 76: Limited Warranty

    Doyon Equipment Inc. does hereby exclude and shall not be liable to purchaser for any consequential or incidental damages including, but not limited to, damages to property, damages for loss of use, loss of time, loss of profits or income, resulting from any breach or warranty.
