Bench Dog Tools Pro-Builder Series Owner's Manual page 4

Contents
of Box
Contents of bag #1
33
21
32
29
20
24
28
25
Hardware bag #2
Item Quantity Part Number
40 2 H0014
41 6 H0012
42 2 H0067
43 2 R0010
44 4 H0175
45 1 H0019
46 1 H0128
47 1 H0129
Contents of bag #2
47
43
46
42
Item Quantity Part Number
20 2 H0168
21 6 H0004
22 4 H0006
23 4 H0005
24 4 H0173
25 18 H0017
26 10 H0103
27 8 H0031
28 4 H0174
29 2 H0171
30 6 H0169
31 12 H0170
32 11 H0050
33 8 H0172
34 2 H0045
35 3 H0037
36 3 H0057
37 3 H0060
38 3 H0163
39 3 H0198
22
31
23
30
34
27
26
Description
T-Knob, 3/8-16 x 2"
T-Knob, 1/4-20 x 1-1/8"
Washer, 3/8" Nylon
Spacer, Alum. Knob
Rubber feet
Wrench, 1/8" hex
Wrench, 5/32" hex
Wrench, 3/16" hex
40
41
45
44
Hardware bag #1
Description
Bolt, 3/8-16 x 2-3/4" Carriage
Bolt, 1/4-20 x 3/4" Hex head
Bolt, 1/4-20 x 50mm (2") Round head
Bolt, 1/4-20 x 40mm (1-1/2") Round head shoulder
Cap screw, 1/4-20 x 1-1/4" Button head socket
Cross Dowel, 1/4-20
Nut, 1/4-20 Nylon insert lock
Nut, 1/4-20 Hex
T-Nut, 1/4-20
Screw, 1/4-20 x 5/8" Flat head socket cap
Screw, 1/4-20 x 1-1/4" Flat head socket cap
Screw, 1/4-20 x 1-3/4" Flat head socket cap
Screw, 1/4-28 x 1/2" Set-socket
Screw, 1/4-20 x 3/4" Socket head cap
Screw, 1/4-20 x 1" Flat head Phillips (black)
Screw, 10-24 x 5/8" Flat head Phillips
Screw, 5/16-18 x 3/4", Flat head Phillips
Screw, 6 x 20 mm, Flat head Phillips
Screw, 8-32 x 1/2", Flat head Phillips
Screw, 10-32 x 5/8", Flat head Phillips
35
38
(Router insert plate mounting screws)
Hardware bag #3 (Hinges)
Item Quantity
48 2
49 2
Contents of bag #3
48
Page 4
Contents of bag #1
37
36
Part Number Description
H0023 Mounting plate, hinge
H0027 Hinge, self closing Euro style
49
39
