- Page 1 8x8 HDMI 2.0 18G Matrix Pro User Manual Eng lis h Benutzerhandbuch Deutsch Manuel Utilisateur Français Manuale Italiano No. 38248 lindy.com Tested to Comply with FCC Standards For Home and Office Use! © LINDY Group - FIRST EDITION...
- Page 3 Thank you for purchasing the 8x8 HDMI 2.0 18G Matrix with audio out. This product has been designed to provide trouble free, reliable operation. It benefits from both a LINDY 2-year warranty and free lifetime technical support. To ensure correct use, please read this manual carefully and retain it for future reference.
- Page 4 User Manual English Operation Front Panel 1. IR receiver window 2. Input/Output Selector – Press the output key 1-8 to select the screen required, the bottom row of numbers on the LED display will start to flash. Then press the input key 1-8 to select the source, the top row of numbers on the LED display will then match the output port number first selected.
- Page 5 Assignment Software Control Download the latest version of the control software from the Lindy website. Using either a RS232 cable or a USB cable, connect the matrix to a PC or laptop. COM Setting – select and connect to the COM port on your PC...
- Page 6 User Manual English Port Set – Select and switch your input and output ports. Click status to display the current connection status, click clear to clear the display information EDID Config – Read and configure the EDID for each input, such as HDR, 3D data rates and audio channel IP Config –...
- Page 7 User Manual English Net Config – Allows you to configure the PC and the Matrix to be in the same LAN. Click “Net config” → “Connect” → “Search Device” → “Sel Device Number” → “Connect” when you can see the device name, it means connection was successful.
- Page 8 User Manual English Command Control Open the application CommUart Assistant Comport Setting Baud Rate: 115200 bps Parity: None Data Bits: 8 bit Stop Bits: 1 bit Enter the Command in the send options Command Function Note Mirror all inputs and outputs @W 04 00 01 02 03 # PTP Function (Ex.
- Page 9 User Manual English Input1 Input2 Input3 Input4 Input5 Input6 Input7 Input8 E.g.: @W 00 00 #: Output 1 display Input1 Output 1 Input1 EDID Setting @W XX AA BB # Parameter Description: XX for configuration of “INPUT EDID” Command Description Input1 Input2 Input3 Input4 Input5 Input6 Input7 Input8 AA for selecting “Video Mode”...
- Page 10 User Manual English EDID Set Page – Edit the EDID settings for each input port IP Config Page – Rename the device and enable/disable DHCP...
- Page 11 LINDY Herstellergarantie – Hinweis für Kunden in Deutschland LINDY gewährt für dieses Produkt über die gesetzliche Regelung in Deutschland hinaus eine zweijährige Hersteller- garantie ab Kaufdatum. Die detaillierten Bedingungen dieser Garantie finden Sie auf der LINDY Website aufgelistet bei den AGBs.
-
Page 12: Recycling Information
Geräte müssen den Sammel- und Rückgabesystemen zugeführt werden! Dort werden sie kostenlos entgegen genommen. Die Kosten für den weiteren Recyclingprozess übernehmen die Gerätehersteller. LINDY bietet deutschen Endverbrauchern ein kostenloses Rücknahmesystem an, beachten Sie bitte, dass Batterien und Akkus den Produkten vor der Rückgabe an das Rücknahmesystem entnommen werden müssen und über die Sammel- und Rückgabesysteme für Batterien separat entsorgt werden müssen.
