INSTALLATION MANUAL
Parts List
1
Driver / left rocker step
1
Passenger / right rocker step
12
Hex bolt, M8
12
Flat washer, M8
12
Lock washer, M8
6
Hex bolt, M10
6
Flat washer, M10
6
Lock washer, M10
6
Bolt, M12 / Nut, M10 plate
6
Flat washer, M12
6
Lock washer, M12
6
Hex nut, M12
Tools Required
Torque wrench
Extension
Socket, 13mm
Socket, 18mm
Socket, 16mm
Torque Specifications
M6 bolt
3 ft.-lbs.
M8 bolt
7 ft.-lbs.
M10 bolt
16 ft.-lbs.
M12 bolt
28 ft.-lbs.
1/4" bolt
3 ft.-lbs.
5/16" bolt
7 ft.-lbs.
3/8" bolt
16 ft.-lbs.
7/16" bolt
20 ft.-lbs.
1/2" bolt
28 ft.-lbs.
Level of Difficulty
Easy
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
For black finishes, mild soap may be used to clean the product.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
PAGE 1 • 2074111-INS-RA • 800.798.0813 • NEED ASSISTANCE?
2074111
Scan
for helpful
install tips
Rear
Front
• ARIESAUTOMOTIVE.COM
