Dormakaba Muto Premium XL120 Installation Instructions Manual
Ceiling mount with dormotion and self-close
Hide thumbs
Also See for Muto Premium XL120:
- Installation instructions manual (13 pages) ,
- Supplemental instructions (7 pages) ,
- Installation manual (22 pages)
Related Manuals for Dormakaba Muto Premium XL120
Summary of Contents for Dormakaba Muto Premium XL120
- Page 1 Muto Premium XL120 Ceiling mount with Dormotion and Self-Close (Glass door) Installation instructions 936013 – 06-2021 | EN |...
-
Page 2: Table Of Contents
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Table of Contents Installation Instructions Table of contents 1 Technical specifications Disengaging the anti-jump Overview Installing the end stops 1.1.1 General information Install glass/rollers in track 1.1.2 Intended use Install floor guide 1.1.3 Glass requirements and fittings... -
Page 3: Technical Specifications
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Technical specifications Installation Instructions 1 Technical specifications Overview • Only properly qualified and specially trained staff are authorized to mount dormakaba glass These instructions are for installation of MUTO hardware. PREMIUM sliding door system XL120 for the following •... -
Page 4: Specifications - Technical Data
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Technical specifications Installation Instructions Specifications - technical data Single Door Double Door XL120 XL120 Ceiling Door leaf weight lbs [kg]* ≤264lbs 2 x ≤264lbs mount [≤120] [2 x ≤120] * Including weight of auxiliary hardware. -
Page 5: Installation Instructions
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Overall Installation Instructions 2 Installation instructions Overall MUTO Premium 936013 06-2021... -
Page 6: Securing Track To Mounting Surface
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Track Installation Instructions Securing track to mounting surface Fig. 1 Track 2.2.1 Ensure the track is properly level and secure it to 2.2.2 Use appropriate fasteners according to the the ceiling per the appropriate measurements on following recommendations. -
Page 7: Door/Wall Dimensions
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Technical specifications Installation Instructions Door/wall dimensions Single door mount Back of track to center of mounting hole in track clear opening height 7/8" (CH) [23] Glass door (DW) Glass door panel 1-3/16"... -
Page 8: A Installing Roller Carriers: On Monolithic Glass Only
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Roller carriers Installation Instructions 2.4A Installing roller carriers: on monolithic glass ONLY Fig. 2 DETERMINE THE LEADING (X) VERSUS TRAILING (Z) EDGE OF THE GLASS. "LEADING IS SIDE CLOSEST TO LATCH CLOSED."... -
Page 9: B Installing Roller Carriers: On Tempered Laminate Glass Only
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Roller carriers Installation Instructions 2.4B Installing roller carriers: on tempered laminate glass ONLY Fig. 3 DETERMINE THE LEADING (X) VERSUS TRAILING (Z) EDGE OF THE GLASS. "LEADING IS SIDE CLOSEST TO LATCH CLOSED."... -
Page 10: Installing Dormotion Start/Stop
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Start/stop Installation Instructions Anti-jump Installing DORMOTION start/stop Fig. 4 Torque PRODUCT SHIPPED WITH 7/8” [22] PIN INSTALLED. PIN CAN BE CHANGED TO 1” [25] IF NECESSARY. Set screws 3 ft lbs... -
Page 11: Installing The End Stops
MUTO XL120 Ceiling Mount with Dormotion and Self-Close End stops Installation Instructions Track Installing the end stops Fig. 6 HANDING THE SELF-CLOSE Slide open to the Slide open to the Legend END STOP right: RIGHT hand left: LEFT hand... -
Page 12: Install Floor Guide
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Floor guide Installation Instructions Install floor guide Fig. 8 XL120 13/16" [20] Floor Glass guide anchor Wall Glass Floor guide REMEMBER ANTI-JUMP IS DISENGAGED! TEMPORARILY REMOVE GLASS AND 2.9.4 ROLLERS FROM TRACK (TO ALLOW OR 2.9.1... -
Page 13: Engaging Anti-Jump
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Anti-jump Installation Instructions Height adjustment 2.11 Engaging anti-jump Fig. 10 Anti- jump 1/4 turn Anti-jump Hex key size adjustment Anti- screw jump XL120 2.11.1 Engage anti-jump on roller carrier. 2.11.2 Using appropriate-size hex key, push anti-jump adjustment screw IN and turn CLOCKWISE 90°... -
Page 14: Adjustment End Stop Location: Leading End Stop
MUTO XL120 Ceiling Mount with Dormotion and Self-Close End stops Installation Instructions 2.13 Adjustment end stop location: LEADING end stop Fig. 12 NOTE: bi-folding: Hex key size Be sure there is a XL120 1/4" [6] gap between END STOP LOCATION:... -
Page 15: Install Dormotion Unit
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Dormotion unit Installation Instructions 2.14 Install DORMOTION unit Fig. 14 Doromotion RIGHT DM UNIT SHOWN Torque units Plates 3 ft lbs screws [3 Nm] Trigger Hex key size Hex screws 3 mm 2.14.1... -
Page 16: Install Optional Dormotion Unit In Opening Cycle
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Dormotion unit Installation Instructions 2.15 Install optional DORMOTION unit in opening cycle Fig. 15 Doromotion units Torque LEFT UNIT SHOWN 3 ft lbs Plates Plates screws [3 Nm] Hex key size... -
Page 17: Adjust Start/Stop Pin Height (If Necessary)
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Start/stop Installation Instructions Self-closing unit 2.16 Adjust start/stop pin height (if necessary) Fig. 16 DORMOTION trigger Start/stop CORRECT INCORRECT screw screw Start/stop 2.16.1 Adjust HEIGHT of start/stop pin, if necessary: •... -
Page 18: Install Self-Close Hold Open Ball
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Self-closing unit Installation Instructions 2.18 Install self-close hold open ball Fig. 18 Legend Closing edge of door Self-close Hex key size hold open ball XL120 • Use two screws and tighten at 2.5 ft lbs [3Nm]. -
Page 19: Install Self-Close Cable Unit
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Self-closing unit Installation Instructions 2.20 Install self-close cable unit Fig. 20 Cable unit Track End stop plates 4" [100] Self-close cable unit Self-close cable unit 2.120.1 Secure self-close cable unit into first groove of •... -
Page 20: Adjust Tension In Self-Close Cable Unit
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Self-closing unit MUTO COMFORT selF-ClOsing Installation Instructions — 2.22 Adjust tension in self-close cable unit Fig. 22 Cable Holder clamp Second holder 'knot' Beginning v = max. 0.2 m/sec v = max. 0,2 m/sek knot of cable 2.22.1... -
Page 21: Cover Clips
MUTO XL120 Ceiling Mount with Dormotion and Self-Close Cover clips Installation Instructions Brush profile 2.23 Cover clips Fig. 23 Cover clip 2.23.1 Insert cover clips into track. (One clip per foot) 2.23.2 Insert perpendicular to track, and turn CLOCKWISE to snap into place. -
Page 22: Install View Protection Clips
MUTO XL120 Ceiling Mount with Dormotion and Self-Close View protection clips Installation Instructions 2.25 Install view protection clips Fig. 25 TO BE USED WITH ONE OR MULTIPLE SIDELITE APPLICATIONS. Empty sliding portion of track (Slide door panel) Sidelite glass... -
Page 23: Install Cover And View Protection Profile
MUTO XL120 Ceiling Mount with Dormotion and Self-Close View protection profile Installation Instructions End caps 2.26 Install cover and view protection profile Fig. 26 Cover clip Cover Cover View protection clip and profile removed for View easier viewing of cover protection installation. - Page 24 USA, Inc. 1 Dorma Drive, Drawer AC Reamstown, PA 17567 T: 717-336-3881 F: 717-336-2106 www.dormakaba.com...
